SERIAL SERVER –
POWER SERIES
PORTSERVER®
TS P MEI
Universal, high-performance RS-232/422/485 serial to
Ethernet connectivity with versatile powering options
PortServer TS P MEI makes it easy to connect RS-232/422/485
serial devices to an IP network. By supporting versatile
powering options like power over Ethernet and serial port
power, this serial server can adapt to many applications where
traditional power options are not available.
Power over Ethernet (802.3af, mid- and end-span support)
makes it possible to run just one Ethernet cable to the device
server for both power and communications. The serial port
power feature enables PortServer TS P MEI to power a device
over serial using Ring Indicator (RI) or DTR pins. Power over
Ethernet can be used in conjunction with a conventional power
supply to provide redundant power capability to the device.
BENEFITS
– 2 or 4 switch-selectable RS-232/422/485 serial ports to
connect virtually any type of serial device over Ethernet
– Supports power over Ethernet (802.3af, end-span and
mid-span) or serial port power for versatile and
redundant powering options
– Patented RealPort® for COM/TTY port control and
management
– Modem emulation allows the device server to appear
as a modem to an attached device
– Monitoring and diagnostic utility
– Secure communication via SSHv2
Available in two- and four-port versions, PortServer TS P MEI
delivers universal, high performance multiport serial-to-
Ethernet connectivity. It is ideal for applications requiring
COM ports, serial tunneling, or where TCP/UDP Socket
functionality is needed.
*The RealPort encryption feature is compatible with AIX, HP-UX, Solaris, Linux,
Windows 2000, Windows XP, Windows 7, Windows 8, Windows 8.1, Windows 10,
Windows Server 2003, Windows Server 2008 and Windows Server 2012. The RealPort
authentication feature is compatible only with Windows 2000, Windows XP, Windows 7,
Windows 8, Windows 8.1, Windows 10, Windows Server 2003, Windows Server 2008 and
Windows Server 2012.
APPLICATION EXAMPLE
NETWORKING WITH POWER FLEXIBILITY
Ethernet
CENTRAL
LOCATION
INTERNET
PORTSERVER® TS P MEI
RELATED PRODUCTS
RS-232/422/485
PortServer®
TS MEI
PortServer®
TS
PortServer®
TS MEI
Hardened
Digi One®
SP
Cables and
Accessories
Router
PBX
SPECIFICATIONS
FEATURES
PortServer® TS 2 P MEI
PortServer® TS 4 P MEI
MANAGEMENT
PROTOCOLS
SOFTWARE
SECURITY
STATUS LEDS
OPERATING SYSTEMS
DIMENSIONS (L X W X D)
WEIGHT
OTHER
INTERFACES
SERIAL
HTTP/HTTPS, CLI, SNMP (read/write), Digi Port Authority-Remote management diagnostics and auto-discovery tool
UDP/TCP, DHCP/RARP/ARP-Ping for IP Address assignment, PPP, Extended Telnet RFC 2217, Telnet, Reverse Telnet,
Modbus to Modbus/TCP protocol conversion support
Supports Digi’s Realport® COM port redirector
SSHv2, SSH/TLS
Link, Activity, Power, Status
AIX, HP-UX, Solaris, Linux®, Windows® 2000, Windows® XP, Windows® 7, Windows® 8, Windows® 8.1, Windows® 10, Windows Server® 2003,
Windows Server® 2008, Windows Server® 2012. Note: TCP/UDP socket services are operating system independent
5.25 in x 3.33 in x 0.95 in (13.34 cm x 8.46 cm x 2.42 cm)
2.25 oz (64.00 g)
802.3af powered Ethernet (mid- and end-span); Full modem and hardware flow control, Modem emulation, Port buffering,
RJ45-DB-9F console adapter included for optional serial configuration
PORTS
ETHERNET
2 RS-232/422/485 RJ-45 (switch selectable); Up to 230 Kbps
throughput; Signal support for TXD, RXD, RTS, CTS, DTR, DSR, DCD
4 RS-232/422/485 RJ-45 (switch selectable); Up to 230 Kbps
throughput; Signal support for TXD, RXD, RTS, CTS, DTR, DSR, DCD
PORTS
POWER REQUIREMENTS
1 RJ-45 10/100 Mbps 10/100Base-T (auto-sensing); Full or half duplex
POWER INPUT
POWER SUPPLY (INCLUDED)
POWER CONSUMPTION
PRODUCT SURGE PROTECTION
(ESD)
9-30 VDC
North America: 12 VDC/.5A max out; 120 VAC in (wall mount); International: 12 VDC/.5A max out; 100-240 VAC in (small brick)
Typical: 4 W; Max: 6 W
4 kV burst (EFT) per EN61000-4-4, 2 kV surge transient per EN61000-4-5
Ethernet Power, IEEE 802.3af compliant, pins 4/5(+) and 7/8(-); 4 kV burst (EFT) per 1000-4-4; 2 kV surge per EN61000-4-5
DC input connector, 9-30 VDC, 525 mA max; Serial Port 1, Pin 1 (RI), 9-30 VDC, 525 mA max
Available on all serial ports; 1 watt available power with selectable voltage level; Pin 1 (RI) 5VDC up to 200 mA max; Pin 9 (DTR) 9VDC up to 100 mA max
POWERED ETHERNET
SERIAL POWER INPUT
SERIAL POWER OUTPUT
ENVIRONMENTAL
OPERATING TEMPERATURE
STORAGE TEMPERATURE
RELATIVE HUMIDITY
ETHERNET ISOLATION
SERIAL PORT PROTECTION
(ESD)
REGULATORY APPROVALS
0° C to 60° C (32° F to 140° F)
-40° C to +85° C (-40° F to +185° F)
5% to 90% (non-condensing)
1500 VAC min per IEEE802.3/ANSI X3.263
15 kV human body model
SAFETY
EMISSIONS/IMMUNITY
UL/CUL60950, IEC60950 & CB
CE, FCC Part 15 (Class A), EN55024, EN55022 Class A, AS/NZS 3548, VCCI V-3/99.05
PART NUMBERS
70001992
70001993
DESCRIPTION
PortServer TS 2 P MEI (mid- and end-span PoE) (International)
PortServer TS 4 P MEI (mid- and end-span PoE) (International)
PORTSERVER TS P MEI - FRONT
PortServer TS Family - Front
PORTSERVER
TS P MEI - Back
BACK
PortServer
TS P MEI -
RJ-45 Serial
Ethernet
LEDs
Ethernet LEDs
LEDs
LEDs
Power
Power
2-Port
4-Port
DIGI SERVICE AND SUPPORT /
You can purchase with confidence knowing that Digi
is always available to serve you with expert technical support and our industry
leading warranty. For detailed information visit www.digi.com/support.
