Evaluation Board for DC Motor Control with the IFX9201
About this document
Scope and purpose
This board user manual provides a basic introduction to the hardware of the H-Bridge Kit 2Go.
The H-Bridge Kit 2Go is a complete low cost system solution for driving small brushed DC motors. It contains a
32bit microcontroller including debug interface, an on board 5 V voltage regulator, reverse polarity protection
for the power supply and an integrated H-Bridge capable of driving up to 6 A peak, the IFX9201SG.
Intended audience
This board user manual is intended for anyone interested in evaluating DC motor control with the IFX9201.
Board User Manual
Please read the Important Notice and Warnings at the end of this document
www.infineon.com
Revision 1.3
2016-10-19
H-Bridge Kit 2Go
Evaluation Board for DC Motor Control with the IFX9201
Table of Contents
Table of Contents
About this document ............................................................................................................................................. 1
Table of Contents .................................................................................................................................................. 2
Power Supply........................................................................................................................................... 4
Selecting a DC motor............................................................................................................................... 4
Connecting the Kit ................................................................................................................................... 4
Port Assignment ...................................................................................................................................... 5
