IPC0044
Datasheet revision 1.0
www.Proto-Advantage.com
QFN-40 to DIP-44 SMT Adapter (0.4 mm pitch, 5 x 5 mm body)
DIMENSIONS
REF.
A
A2
B
C
B2
C2
D
D2
E
F
G
H
MIN.
mm
TYP.
4.20
4.20
0.60
0.20
3.50
3.50
0.20
0.35
0.40
MAX.
MIN.
inches
TYP.
MAX.
0.600
0.100
0.025
Top View (SMT Footprint)
B
A
C
E
D
A2
C2
B2
D2
(Representative drawing only - not to scale)
1
© 2010 Proto Advantage Inc.
Bottom View (DIP Pins)
F
H
G
(Representative drawing only - not to scale)
Side View (DIP Pins)
F
(Representative drawing only - not to scale)
