Smallest, Most Reliable Gigabit Switching
Media Converter
Giga-MiniMc SFP with LFPT & Giga-MiniMc TX/SX & TX/LX
PRODUCT FEATURES
One 1000Base-SC or 1000Base-LX fiber port
One 10/100/1000 Mbps twisted pair port
Status LEDs
AutoCross automatic selection between crossover or
straight-through connection
• 18 connections in the 1.5U high IE-PowerTray/18 Chassis
• SFP available
•
•
•
•
Media conversion is the most cost-effective solution for extending the
productive life of legacy wiring plants and equipment while allowing
implementation of new technologies. Media conversion’s greatest
benefits are flexibility and cost savings.
Measuring less than 3.5 inches deep and 2 inches wide, the Giga-
MiniMc is the industry’s smallest gigabit media converter with both
data connections on the same side of the unit, and at a fraction of the
cost of other alternatives. Plug-and-play operation with a variety of
model types and powering options make the Giga-MiniMc easy and
convenient to use.
ACCESSORiES
806-39105 - DIN Rail Clip
806-39638 - Double-USB Power Cable, 36”/.9m
806-39650 - 12”/.3m Barrel-Connector Power Cable
850-13086 - IE-PowerTray/18-AC (-20°C to +70°C), 18-slot AC powered chassis
895-39229 - Wall Mount Bracket
ORDERinG inFORMATiOn
Model
Fiber raNge
Fiber
NuMber
Ports
giga-MiniMc sFP with lFPt
856-10747
SFP
1
Various
giga-MiniMc tX/sX and tX/lX
220/550
856-10730
SX-MM850-SC
1
km
220/550
856-10730-ST SX-MM850-SC
1
km
856-10728
LX-MM1300-SC
1
2 km
856-10731
LX-SM1310-SC
1
10 km
LX-SM1310/
856-10732
1
40 km
PLUS-SC
LX-SM1550/
856-10733
1
80 km
LONG-SC
LX-SM1550/
856-10729
1
100 km
XLONG-SC
siNgle straNd Fiber **
856-10734
SSLX-SM1310-SC 1
15 km
856-10735
SSLX-SM1550-SC 1
15 km
856-10742
SSBX-SM1310-SC 1
10 km
856-10743
SSBX-SM1490-SC 1
10 km
SSLX-SM1310/
856-10736
1
40 km
PLUS-SC
SSLX-SM1550/
856-10737
1
40 km
PLUS-SC
SSBX-SM1310/
856-10744
1
30 km
PLUS-SC
SSBX-SM1490/
856-10745
1
30 km
PLUS-SC
SSLX-SM1490/
856-10738
1
70 km
LONG-SC
SSLX-SM1550/
856-10739
1
70 km
LONG-SC
etherNet etherNet
Ports
CoNNeCtor
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
* SFP Fiber sold separately
** These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B+B IMC LLC single-strand fiber product.
Giga-MiniMc also available in CWDM Fiber. Call for details.
www.bb-smartworx.com
|
Enabling connEctEd intElligEncE
Giga-MiniMc with SFP & Giga-MiniMc TX/SX & TX/LX_2615ds
Smallest, Most Reliable Gigabit
Switching Media Converter
Giga-MiniMc SFP with LFPT & Giga-MiniMc TX/SX & TX/LX
SpecificationS
Technical
Plug-and-play operation
RJ45 and SC or SFP connectors
IEEE 802.3 10Base-T twisted pair
IEEE 802.3u 100Base-TX twisted pair
IEEE 802.3ab 1000Base-T twisted pair
IEEE 802.3z 1000Base-LX or SX fiber
MTU: Supports Jumbo Frames up to 10240 bytes (Giga-MiniMc SFP)
Country-specific, high-reliability power adapter
Layer 2 packet switching, store and forward (forwarding rate: 14,881 pps for 10
Mbps, 148,810 pps for 100 Mbps, 1,488,096 pps for 1000 Mbps)
Auto-Cross for MDI/MDIX
Status LEDs
Mechanical
Dimensions
Shipping Weight
Power
5 VDC, 600mA
120 VAC, 0.1A
environMental
Operating Temperature:
Storage Temperature:
Operating Humidity
regulatory aPProvals
FCC Class A
UL/cUL, CSA, CE
0.83”H x 1.80”W x 3.35”D
(2.11 x 4.57 x 8.51 cm)
0.7 lbs (.317 kg)
+32° F to +122° F (0° C to +50° C)
-31° F to +167° F (-35° C to +75° C);
5% to 95% (non-condensing)
MEChAniCAl DiAGRAM
(dimensions in inches & millimeters)
1.40
(35,6)
.51
(12,9)
REF
.31
(7,9)
.45
(11,4)
3.35
(85,1)
.43
(11,0)
.46
(11,7)
1.81
(46,0)
.32
(8,1)
.44
(11,2)
.84
(21,3)
