BUK7Y14-80EX

Description
ARM Microcontrollers - MCU Ultra Low M3 ARM 256 Kbytes 32 MHz
Categorysemiconductor    Discrete semiconductor
File Size341KB,13 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Download Datasheet Parametric View All

BUK7Y14-80EX Online Shopping

Suppliers Part Number Price MOQ In stock
BUK7Y14-80EX - - View Buy Now

BUK7Y14-80EX Overview

ARM Microcontrollers - MCU Ultra Low M3 ARM 256 Kbytes 32 MHz

BUK7Y14-80EX Parametric

Parameter NameAttribute value
Product CategoryMOSFET
ManufacturerNXP
RoHSDetails
TechnologySi
Mounting StyleSMD/SMT
Package / CaseLFPAK56-5
Number of Channels1 Channel
Transistor PolarityN-Channel
Vds - Drain-Source Breakdown Voltage80 V
Id - Continuous Drain Current65 A
Rds On - Drain-Source Resistance9.2 mOhms
Vgs th - Gate-Source Threshold Voltage3 V
Vgs - Gate-Source Voltage20 V
Qg - Gate Charge44.8 nC
Minimum Operating Temperature- 55 C
Maximum Operating Temperature+ 175 C
ConfigurationSingle
Channel ModeEnhancement
PackagingMouseReel
PackagingCut Tape
PackagingReel
Fall Time17.9 ns
Pd - Power Dissipation147 W
Rise Time13.2 ns
Factory Pack Quantityyxxctvzf1500
Transistor Type1 N-Channel
Typical Turn-Off Delay Time33.3 ns
Typical Turn-On Delay Time9.1 ns
LF
BUK7Y14-80E
8 May 2013
PA
K
56
N-channel 80 V, 14 mΩ standard level MOSFET in LFPAK56
Product data sheet
1. General description
Standard level N-channel MOSFET in an LFPAK56 (Power SO8) package using
TrenchMOS technology. This product has been designed and qualified to AEC Q101
standard for use in high performance automotive applications.
2. Features and benefits
Q101 compliant
Repetitive avalanche rated
Suitable for thermally demanding environments due to 175 °C rating
True standard level gate with V
GS(th)
rating of greater than 1 V at 175 °C
3. Applications
12 V, 24 V and 48 V Automotive systems
Motors, lamps and solenoid control
Transmission control
Ultra high performance power switching
4. Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
Conditions
T
j
≥ 25 °C; T
j
≤ 175 °C
V
GS
= 10 V; T
mb
= 25 °C;
Fig. 1
T
mb
= 25 °C;
Fig. 2
V
GS
= 10 V; I
D
= 15 A; T
j
= 25 °C;
Fig. 11
V
GS
= 10 V; I
D
= 15 A; V
DS
= 64 V;
T
j
= 25 °C;
Fig. 13; Fig. 14
-
12.9
-
nC
Min
-
-
-
Typ
-
-
-
Max
80
65
147
Unit
V
A
W
Static characteristics
drain-source on-state
resistance
-
9.2
14
Dynamic characteristics
Q
GD
gate-drain charge
