BD60HA3MEFJ-ME2

Description
LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO
Categorysemiconductor    Power management
File Size690KB,25 Pages
ManufacturerROHM Semiconductor
Websitehttps://www.rohm.com/
Download Datasheet Parametric Compare View All

BD60HA3MEFJ-ME2 Online Shopping

Suppliers Part Number Price MOQ In stock
BD60HA3MEFJ-ME2 - - View Buy Now

BD60HA3MEFJ-ME2 Overview

LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO

BD60HA3MEFJ-ME2 Parametric

Parameter NameAttribute value
Product CategoryLDO Voltage Regulators
ManufacturerROHM Semiconductor
RoHSDetails
Mounting StyleSMD/SMT
Package / CaseHTSOP-J-8
Output Voltage6 V
Output Current0.3 A
Number of Outputs1 Output
Quiescent Current-
Input Voltage MAX8 V
Input Voltage MIN4.5 V
Output TypeFixed
Minimum Operating Temperature- 40 C
Maximum Operating Temperature+ 105 C
Load Regulation25 mV
Dropout Voltage0.6 V
QualificationAEC-Q100
PackagingReel
Development Kit-
Dropout Voltage - Max0.9 V
Ib - Input Bias Current600 uA
Line Regulation25 mV
Operating Supply Current-
Output Voltage Range-
Pd - Power Dissipation2110 mW
ProductLinear Voltage Regulators
PSRR / Ripple Rejection - Typ-
Reference Voltage-
Factory Pack Quantity2500
Tolerance-
TypeAutomotive
Voltage Regulation Accuracy1 %
Unit Weight0.001905 oz
Datasheet
Automotive 0.3A Variable Output
LDO Regulator
BDxxHA3MEFJ-M
●General
Description
BDxxHA3MEFJ-M is a LDO regulator with output current 0.3A. The output accuracy is ±1% of output voltage. With external
resistance, it is available to set the output voltage at random (from 1.5V to 7.0V).It has package type: HTSOP-J8. Over
current protection (for protecting the IC destruction by output short circuit), circuit current ON/OFF switch (for setting the
circuit 0μA at shutdown mode), and thermal shutdown circuit (for protecting IC from heat destruction by over load condition)
are all built in. It is usable for ceramic capacitor and enables to improve smaller set and long-life.
●Features
High accuracy reference voltage circuit
Built-in Over Current Protection circuit (OCP)
Built-in Thermal Shut Down circuit (TSD)
With shut down switch
AEC-Q100 Qualified
●Package
HTSOP-J8
(Typ.)
(Typ.)
(Max.)
4.90mm x 6.00mm x 1.00mm
●Key
Specifications
Input power supply voltage range:
4.5V to 8.0V
Output voltage range(Variable type):
1.5V to 7.0V
Output voltage(Fixed type): 1.5V/1.8V/2.5V/3.0V/3.3V
5.0V/6.0V/7.0V
Output current:
0.3A (Max.)
Shutdown current:
0μA(Typ.)
Operating temperature range:
-40℃ to +105℃
HTSOP-J8
●Typical
Application Circuit
V
CC
C
IN
EN
GND
FIN
V
O
R
1
FB
R
2
C
OUT
C
IN
V
CC
V
O
V
O_S
C
OUT
EN
GND
FIN
C
IN
,C
OUT
: Ceramic Capacitor
C
IN
,C
OUT
: Ceramic Capacitor
○Product
structure:Silicon monolithic integrated circuit
www.rohm.com
© 2012 ROHM Co., Ltd. All rights reserved.
TSZ22111½14½001
○This
product is not designed protection against radioactive rays.
1/21
TSZ02201-0R6R0AN00250-1-2
2012.8.31 Rev.001

BD60HA3MEFJ-ME2 Related Products

BD60HA3MEFJ-ME2 BD15HA3MEFJ-ME2 BD33HA3MEFJ-ME2 BD30HA3MEFJ-ME2 BD00HA3MEFJ-ME2 BD18HA3MEFJ-ME2
Description LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO LDO Voltage Regulators IC Pwr Linear Reg Single Output LDO
Product Category LDO Voltage Regulators LDO Voltage Regulators LDO Voltage Regulators LDO Voltage Regulators LDO Voltage Regulators LDO Voltage Regulators
Manufacturer ROHM Semiconductor ROHM Semiconductor ROHM Semiconductor ROHM Semiconductor ROHM Semiconductor ROHM Semiconductor
RoHS Details Details Details Details Details Details
Mounting Style SMD/SMT SMD/SMT SMD/SMT SMD/SMT SMD/SMT SMD/SMT
Package / Case HTSOP-J-8 HTSOP-J-8 HTSOP-J-8 HTSOP-J-8 HTSOP-J-8 HTSOP-J-8
Output Voltage 6 V 1.5 V 3.3 V 3 V Adj 1.8 V
Output Current 0.3 A 300 mA 300 mA 300 mA 300 mA 300 mA
Number of Outputs 1 Output 1 Output 1 Output 1 Output 1 Output 1 Output
Input Voltage MAX 8 V 8 V 8 V 8 V 8 V 8 V
Input Voltage MIN 4.5 V 4.5 V 4.5 V 4.5 V 4.5 V 4.5 V
Output Type Fixed Fixed Fixed Fixed Adjustable Fixed
Minimum Operating Temperature - 40 C - 40 C - 40 C - 40 C - 40 C - 40 C
Maximum Operating Temperature + 105 C + 105 C + 105 C + 105 C + 105 C + 105 C
Load Regulation 25 mV 25 mV 25 mV 25 mV 25 mV 25 mV
Dropout Voltage 0.6 V 600 mV 600 mV 600 mV 600 mV 600 mV
Qualification AEC-Q100 AEC-Q100 AEC-Q100 AEC-Q100 AEC-Q100 AEC-Q100
Packaging Reel Reel Reel Reel Reel Reel
Dropout Voltage - Max 0.9 V 900 mV 900 mV 900 mV 900 mV 900 mV
Ib - Input Bias Current 600 uA 600 uA 600 uA 600 uA 600 uA 600 uA
Line Regulation 25 mV 25 mV 25 mV 25 mV 25 mV 25 mV
Pd - Power Dissipation 2110 mW 2.11 W 2.11 W 2.11 W 2.11 W 2.11 W
Product Linear Voltage Regulators LDO Regulators LDO Regulators LDO Regulators LDO Regulators LDO Regulators
Type Automotive Automotive LDO Regulator Automotive LDO Regulator Automotive LDO Regulator Automotive LDO Regulator Automotive LDO Regulator
Voltage Regulation Accuracy 1 % 1 % 1 % 1 % 1 % 1 %
Unit Weight 0.001905 oz 0.001905 oz 0.001905 oz 0.001905 oz 0.001905 oz 0.001905 oz
Factory Pack Quantity 2500 2500 2500 - 2500 2500
