General Purpose Silicon Rectifiers
1N5400-G Thru. 1N5408-G
Voltage: 50 to 1000 V
Current: 3.0 A
RoHS Device
Features
-Low forward voltage drop.
-High reliability.
-High current capability.
1.000(25.40) Min.
0.052(1.32)
DIA.
0.048(1.22)
DO-27 (DO-201AD)
-High surge current capability.
Mechanical data
-Case: Molded plastic
-Epoxy: UL 94V-0 rate flame retardant
-Polarity: Color band denotes cathode end
-Lead: Axial leads, solderable per MIL-STD-202,
method 208 guaranteed
-Mounting position: Any
-Weight: 1.2 grams
0.375(9.53)
0.335(8.51)
0.220(5.60)
DIA.
0.197(5.00)
1.000(25.40) Min.
Dimensions in inches and (millimeter)
Maximum Ratings and Electrical Characteristics
(at T =25°C unless otherwise noted)
A
Ratings at 25°C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
.375”(9.5mm) Lead length
@T
A
=75°C
Peak forward surge current, 8.3ms single
half sine-wave superimposed on rated load
(JEDEC method)
Maximum instantaneous forward voltage @3.0A
Maximum DC reverse current
at rated DC blocking voltage
@T
J
=25°C
@T
J
=100°C
Symbol
1N5400 1N5401 1N5402 1N5404 1N5406 1N5407 1N5408
Unit
-G
-G
-G
-G
-G
-G
-G
V
RRM
V
RMS
V
DC
I
F(AV)
50
35
50
100
70
100
200
140
200
400
280
400
3.0
600
420
600
800
560
800
1000
700
1000
V
V
V
A
I
FSM
V
F
I
R
R
θJA
T
J
T
STG
200
1.0
5.0
100
18
-65 to +125
-65 to +150
A
V
μA
°C/W
°C
°C
Typical thermal resistance (Note 1)
Operating temperature range
Storage temperature range
NOTES:
1. Thermal resistance from junction to ambient 0.375” (9.5mm) lead length.
REV:A
QW-BG015
Page 1
General Purpose Silicon Rectifiers
Rating and Characteristic Curves (1N5400-G Thru. 1N5408-G)
Fig.1 - Maximum Forward Current
Derating Curve
3.0
Fig.2 - Typical Instantaneous Forward
Characteristics Per Bridge Element
100
Instantaneous Forward Current, (A)
Average Forward Current, (A)
10
2.0
1
1.0
Single phase half wave 60Hz
Resistive or inductive load
0.375” (9.5mm) lead length
0.1
T
J
=25°C
Pulse width=300us
1% Duty cycle
0
0
25
50
75
100
125
150
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
Ambient Temperature, (°C)
Instantaneous Forward Voltage, (V)
Fig.3 - Maximum Non-repetitive Forward
Surge Curren Per Bridge Element
Fig.4 - Typical Reverse Characteristics
Per Bridge Element
Instantaneous Reverse Current, (µA)
200
10.0
T
J
=100°C
Peak Forward Surge Current, (A)
100
1.0
50
0.1
T
J
=25°C
8.3ms single half sine-wave
(JEDEC Method)
10
1
10
100
0.01
0
20
40
60
80
100 120 140
Number of Cycles at 60Hz
Percent of Rated Peak Reverse Voltage, (V)
REV:A
QW-BG015
Page 2
