MISTRAL
AC/DC Multirange FAST CHARGER
Rev. 01
FEATURES
LINE VOLTAGE 90 - 264 VAC
SINGLE OUTPUT MAX 8W
DESIGNED FOR ON LINE CHARGING OF
MOBILE PHONES
EMC COMPLIANCE ACCORDING TO EU
AND US DIRECTIVES
SAFETY
EN60950
APPROVAL
ACCORDING
TO
PRODUCT VIEW
CE AND UL MARKED. AUSTRALIA, UK,
SOUTH AFRICA AND CHINA MARKING
UPON REQUEST
OUTPUT CURRENT AND VOLTAGE LEVELS
ACCORDING TO CUSTOMER REQUIRE-
MENTS
OUTPUT VOLTAGE PRECISION: +/- 5%
OUTPUT CURRENT PRECISION : +/- 12%
OUTPUT RIPPLE VOLTAGE <100 mVpp
INPUT FUSE PROTECTION
OUTPUT SHORT CIRCUIT PROTECTION
2 WIRES DC CORD TERMINATED WITH
ANY CUSTOM CONNECTOR
AVAILABLE WITH A VARIETY OF AC PLUGS
LOW STAND BY POWER
(Robin Housing, all plug types)
ORDERING NUMBER: GSAC-xxCCCy
Plug Type:
EURO
UK
US
AUSTRALIA
INDIA/S. Africa
Part Number:
GSAC-xxCCC1
GSAC-xxCCC2
GSAC-xxCCC3
GSAC-xxCCC4
GSAC-xxCCC5
CHINA
GSAC-xxCCC6
xx = Output Current level (2 Digits)
CCC= Customer Identifier (3 Digits)
y = plug type
DESCRIPTION
The Fast Charger MISTRAL has been designed
for charging NiMH and NiCd batteries in hand
held mobile phones. MISTRAL is a low cost high
efficiency AC/DC switching mode constant volt-
age & current generator. The output voltage and
current levels are set up by design in accordance
with customer requirements.
1/4
January 2000
MISTRAL
Typical reference values in this datasheet are 8V,
700 mA with the input Vac ranging from 90 to 264
Vrms.
Coming into the small Robin housing, MISTRAL
can be assembled with a variety of AC plugs
identified by specific ordering numbers. Interface
to the phone is ensured via a 2 wires cord with
strain relief, terminated with customer specified
connector. Typical weight is 70 grams only, with-
out cable.
AGENCY Approvals
The charger is certified by competent agencies to
comply with most popular safety and EMC re-
quirements, including but not limited to:
EN60950
UL1950
ETS300-342-1
FCC part 15 (specific version upon request)
ELECTRICAL CHARACTERISTICS
(Tamb=25
o
C, unless otherwise specified.)
Symbol
Vi
Vo
Io
Vor
Vis
Top
Tstg
n
Parameter
Input Voltage
Output Voltage limit
Output Current limit
Output Ripple
Isolation voltage
Operating
Temperature
Ambient
No load
1<Vout<Vo limit
Io=Ilimit
Vbatt=4V
output,
t=60s
3000
0
-20
75%
50
70
Test Condition
Min.
90
7.6
600
8.0
700
Typ.
Max.
264
8.4
800
100
Unit
Vrms
V
mA
mVpp
Vrms
o
o
Input to
(EN60950)
C
C
Storage Temperature Range
efficiency
TYPICAL OUTPUT CHARACTERISTIC
Vo (V)
8
700
Io (mA)
2/4
MISTRAL
MECHANICAL DATA EURO plug version
(dimensions in mm)
MECHANICAL DATA UK plug version
(dimensions in mm)
3/4
MISTRAL
MECHANICAL DATA US plug version
(dimensions in mm)
Fast Chargers SELECTION chart
PARAMETER
INPUT VOLTAGE RANGE - Vrms
MAX OUTPUT POWER - Watt
OUTPUT VOLTAGE ACCURACY
OUTPUT CURRENT ACCURACY
OUTPUT VOLTAGE RIPPLE - mVpp
ISOLATION VOLTAGE- Vrms
OPERATING AMBIENT TEMPERATURE -
o
C
STORAGE TEMPERATURE RANGE -
o
C
AC INPUT FUSE PROTECTION
DC OUTPUT SHORT CIRCUIT PROTECTION
WEIGHT (without cable) - Grams
GHIBLI
90 - 264
8
+/- 5%
+/- 8%
< 100
> 3000
0 - 50
-20 +70
YES
YES
70
MISTRAL
90 - 264
8
+/- 5%
+/- 12%
< 100
> 3000
0 - 50
-20 +70
YES
YES
70
JOSEPH
90 - 264
4
+/- 10%
+/- 20%
< 100
> 3000
0 - 50
-20 +70
YES
YES
70
