SERIES:
PJ-067X
│
DESCRIPTION:
DC POWER JACK
FEATURES
• mounting hardware includes nut and washer
• panel mount
• metal bushing
RoHS
PART NUMBER KEY
PJ-067
X
Base Number
Center Pin Diameter
A = ø2.0 mm
B = ø2.5 mm
SPECIFICATIONS
parameter
rated input voltage
rated input current
contact resistance
insulation resistance
voltage withstand
insertion/withdrawl force
operating temperature
life
at 500 Vdc
for 1 minute
0.2
-25
5,000
100
500
3.0
70
conditions/description
min
typ
24
5
30
max
units
Vdc
A
mΩ
MΩ
Vac
kgf
°C
cycles
SOLDERABILITY
parameter
hand soldering
wave soldering
conditions/description
for 3~5 seconds at
for 3~5 seconds at
min
295
245
typ
300
250
max
305
255
units
°C
°C
cui.com
For more information, please visit the
product page
|
For information on related products, view
External Power Supplies
CUI Inc
│
SERIES:
PJ-067X
│
DESCRIPTION:
DC POWER JACK
date
12/19/2012
│
page
2 of 3
MECHANICAL DRAWING
units: mm[inches]
TOLERANCE:
±0.3mm (unless otherwise specified)
center pin
terminal 1
terminal 2
terminal 3
bushing
insulator
plastic
nut
washer
MATERIAL
brass
brass
phosphor bronze
brass
brass
red vulcanite fiber
PBT
brass
steel
nickel
nickel
PLATING
nickel
silver
silver
silver
nickel
5/16X32W
refer to
schematic
11.00 0.433
0.10
5.70 0.224
0.10
5.70 0.224
0.20
2.70 0.106
3.90 0.154
3.80 0.150
8.10 0.319
11.20 0.441
14.20 0.559
2
3
7.80 0.307
0.20
10.40 0.409
0.20
4.50 0.177
(3 PLCS)
2.50 0.098
(3 PLCS)
1
3.00 0.118
0.20
9.55 0.376
4.80 0.189
8.10 0.319
10.00 0.394
2.10 0.083
11.20 0.441
2
14.20 0.559
3
1
4.80 0.189
5/16x32W
PCB LAYOUT
TOP VIEW
3.00X0.70
(3 PLCS)
Schematic
10.10 0.398
8.10 0.319
1
3
2
Model
MATING PLUG
Jack Insertion Depth: 8.4mm
PJ-067A
PJ-067B
Center Pin
ø2.0 mm
ø2.5 mm
0.30 0.012
