8BA103Z05SA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 8BA103Z05SA

8BA103Z05SA: DescriptionCircular MIL Spec Connector 5P Socket Receptacle In-Line Size 3; CategoryThe connector The connector; File Size2MB，6 Pages; ManufacturerSOURIAU; Environmental Compliance

Download Datasheet Parametric Compare View All

8BA103Z05SA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	8BA103Z05SA	-	-	View	Buy Now

8BA103Z05SA Overview

Circular MIL Spec Connector 5P Socket Receptacle In-Line Size 3

8BA103Z05SA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	SOURIAU
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
Other features	STANDARD: MIL-DTL-38999, POLARIZED
Back shell type	SOLID
Body/casing type	RECEPTACLE
Connector type	MIL SERIES CONNECTOR
Contact to complete cooperation	GOLD OVER NICKEL
Contact completed and terminated	Gold (Au) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
Coupling type	SNAP
DIN compliance	NO
empty shell	NO
Environmental characteristics	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	YES
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell surface	BLACK ZINC NICKEL PLATED
Shell material	ALUMINUM ALLOY
Housing size	3
Termination type	CRIMP
Total number of contacts	5
Base Number Matches	1

Preview

Download Datasheet

View All

8BA Break Away

Miniature Product with a Break Away Release

Space saving with scoop proof connector for harsh and EMI applications.

A compact solution

A high density solution

Excellent features

RoHS and Cadmium free

Robustness

Integrated backshell

Diameter up to 45% smaller than size 9 (D38999).

Up to 50% shorter.

With #26 contacts (according 39029).

5 layouts (size 3, 5 and 7 with #22 & #26).

Designed for D38999 requirements.

IP67 sealing when mated, ballseal (EMI).

Available in zinc nickel (RoHS) plating, as well as

nickel and olive drab cadmium.

Connector available with stainless steel (1

500

matings) and aluminum shell (500 matings).

Cost and space saving.

8BA103Z05SA Related Products

	8BA103Z05SA	8BA603Z05PN	8BA607Z09PN	8BA103Z05SN	8BA107Z09SN	8BA605Z06PN	8BA607Z09PA	8BA107Z09SA
Description	Circular MIL Spec Connector 5P Socket Receptacle In-Line Size 3	Circular MIL Spec Connector 5P Pin Plug Size 3 Self-Locking 5POS	Circular MIL Spec Connector 9P Pin Plug Size 7 Self-Locking 9POS	Circular MIL Spec Connector 5P Socket Receptacle In-Line Size 3	Circular MIL Spec Connector 9P Socket Receptacle In-Line Size 7	Circular MIL Spec Connector 6P Pin Plug Size 5 Self-Locking 6POS	Circular MIL Spec Connector 9P Pin Plug Size 7 Self-Locking 9POS	Circular MIL Spec Connector 9P Socket Receptacle In-Line Size 7
package instruction	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT	ROHS COMPLIANT
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Other features	STANDARD: MIL-DTL-38999, POLARIZED	STANDARD: MIL-DTL-38999	STANDARD: MIL-DTL-38999	STANDARD: MIL-DTL-38999	STANDARD: MIL-DTL-38999	STANDARD: MIL-DTL-38999	STANDARD: MIL-DTL-38999, POLARIZED	STANDARD: MIL-DTL-38999, POLARIZED
Back shell type	SOLID	SOLID	SOLID	SOLID	SOLID	SOLID	SOLID	SOLID
Body/casing type	RECEPTACLE	PLUG	PLUG	RECEPTACLE	RECEPTACLE	PLUG	PLUG	RECEPTACLE
Connector type	MIL SERIES CONNECTOR	MIL SERIES CONNECTOR	MIL SERIES CONNECTOR	MIL SERIES CONNECTOR	MIL SERIES CONNECTOR	MIL SERIES CONNECTOR	MIL SERIES CONNECTOR	MIL SERIES CONNECTOR
Contact to complete cooperation	GOLD OVER NICKEL	GOLD OVER NICKEL	GOLD OVER NICKEL	GOLD OVER NICKEL	GOLD OVER NICKEL	GOLD OVER NICKEL	GOLD OVER NICKEL	GOLD OVER NICKEL
Contact completed and terminated	Gold (Au) - with Nickel (Ni) barrier	Gold (Au) - with Nickel (Ni) barrier	Gold (Au) - with Nickel (Ni) barrier	Gold (Au) - with Nickel (Ni) barrier	Gold (Au) - with Nickel (Ni) barrier	Gold (Au) - with Nickel (Ni) barrier	Gold (Au) - with Nickel (Ni) barrier	Gold (Au) - with Nickel (Ni) barrier
Contact point gender	FEMALE	MALE	MALE	FEMALE	FEMALE	MALE	MALE	FEMALE
Contact material	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Coupling type	SNAP	SNAP	SNAP	SNAP	SNAP	SNAP	SNAP	SNAP
DIN compliance	NO	NO	NO	NO	NO	NO	NO	NO
empty shell	NO	NO	NO	NO	NO	NO	NO	NO
Environmental characteristics	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT	ENVIRONMENT/FLUID/IMMERSION/TEMPERATURE RESISTANT
Filter function	NO	NO	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO	NO	NO
JESD-609 code	e4	e4	e4	e4	e4	e4	e4	e4
MIL compliance	YES	YES	YES	YES	YES	YES	YES	YES
Plug information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO	NO	NO	NO	NO	NO	NO	NO
Installation type	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Shell surface	BLACK ZINC NICKEL PLATED	BLACK ZINC NICKEL PLATED	BLACK ZINC NICKEL PLATED	BLACK ZINC NICKEL PLATED	BLACK ZINC NICKEL PLATED	BLACK ZINC NICKEL PLATED	BLACK ZINC NICKEL PLATED	BLACK ZINC NICKEL PLATED
Shell material	ALUMINUM ALLOY	ALUMINUM ALLOY	STAINLESS STEEL	ALUMINUM ALLOY	STAINLESS STEEL	STAINLESS STEEL	STAINLESS STEEL	STAINLESS STEEL
Housing size	3	3	7	3	7	5	7	7
Termination type	CRIMP	CRIMP	CRIMP	CRIMP	CRIMP	CRIMP	CRIMP	CRIMP
Total number of contacts	5	5	9	5	9	6	9	9
Is it Rohs certified?	conform to	conform to	-	conform to	-	conform to	-	conform to
Maker	SOURIAU	-	SOURIAU	SOURIAU	SOURIAU	SOURIAU	SOURIAU	-
Base Number Matches	1	1	-	1	-	1	-	1
