Cool Edge®
Features:
Supports data speed from 6Gbps to 25Gbps per differential pair
female connectors.
Overview:
A 0.8 Pitch High-speed Signal and Power Hybrid Card-Edge Connector. The Cool Edge can
provide tailor made solutions (carries 25Gbps Ethernet and 16Gbos PCIe, and single and signal
altogether). With modular base tooling, the connector can be all power, all signal, or hybrid.
The Cool Edge has balanced Signal Integrity Characteristics, such as a very low loss and cross-
talk for LVDS at data rate 25-28Gbps or upto 56Gbps (PAM4).
Applications:
Datacom:
Server
Networking:
Telecom:
Datacenter.
To learn more about Cool Edge connectors:
web: amphenolcanada.com
email: sales@amphenolcanada.com
Cool Edge®
Technical Characteristics:
Housing
Contact
Latch
Board Locks
Pickup Cap
Ma ng Force
Unma ng Force
Current Ra ng for Power Pin
Current Ra ng for Signal Pin
Contact
Board Lock
Material
High temperature Thermoplas c black UL94 - V0
Copper Alloy
High Temperature Thermoplas c Black UL 94 - V0
Copper Alloy
SPCC
.
Stainless steel
Mechanical
25N max.
5N min.
Electrical
20A - 25A/Pin
0.5A - 1.2A/Pin
Pla ng
Copper Alloy, Nickel Underplated, Selec ve Gold on Ma ng Area
1.27 min. ma e n over 127 - 2.54 Um Nickel Underplated
Ordering Information:
Cool Edge:
CE X X
T - Tailor Made
1 - Generation 1
2 - Generation 2
2 - 2 pin min.
4 - 4 pin.
12 - 12 pin max.
10 - 10 pin min.
12 -12 pin.
200 - 200 pin max.
01, 02, ....
X X X X X XX
1 - 0.76um Au
0 - 1.60mm (1.57mm)
1 - 1.0mm
G - With Guide Hole and SMT Board Lock
0 - Without Guide Hole and With SMT Board Lock
1 - Without Guide Hole and Without Board Lock
2 - With Guide Hole and Without Board Lock
4 - Without Guide Hole and With Through Hole Board Lock
1 - SMT for Signal, Through Hole for Power
2 - Press Fit for Signal and Power
4 - SMT for Signal and Power
5 - Stradle Mount for Signal and Power
0 - Without Latch
L - With Latch Type 1
2 - With Latch Type 2
1 - Backplane (Vertical)
2 - Coplanar Plane
Slim Cool Edge:
T - Tailor Made
1 - Generation 1
2 - Generation 2
2 - 2 pin min.
4 - 4 pin.
12 - 12 pin max.
XXX
1 - 0.76um Au
01, 02, ....
020 - 20 pin min.
040 -40 pin.
180 - 180 pin
0 - 1.0mm
1 - 1.60mm
2 - 2.00mm
4 - 1.4mm
0 - Tailor Made
1 - 0.8mm
2 - 0.6mm
0 - Without Latch Board Lock
1 - With Latch and SMT Board Lock
2 - With Latch and without SMT Board Lock
4 - With Latch and Through Hole Board Lock
5 - With Latch and Without Through Hole Board Lock
6 - Without Latch and With Through Hole Board Lock
7 - With Latch and Forklock Board Lock
8 - With Latch amd Without Forklock Board Lock
1 - SMT for Signal, Through Hole for Power
2 - Through Hole for Signal and Power
1 - Backplane (Vertical)
2 - Coplanar Plane
To learn more about Cool Edge connectors:
web: amphenolcanada.com
email: sales@amphenolcanada.com
