Printed Circuit Board PCB Pin Receptacles
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 , 3
Printed Circuit Board (PCB) Pin Receptacles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
Printed Circuit Board (PCB) Receptacles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 7
FASTON Printed Circuit Board Tabs and Receptacles . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 16
AMP-BARREL Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 - 19
AMP-BARREL Terminals - Application Tooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
QUADRA-MATE Wire-to-Printed Circuit Board Terminal . . . . . . . . . . . . . . . . . . . . . . . . . 21 - 22
Printed Circuit Board Disconnects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 - 25
AMP EDGE Single Head Printed Circuit Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26, 27
Miniature AMP-IN Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28, 29
Low Profile Miniature AMP-IN Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Test Probe Receptacles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Power Taps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 - 36
Application Tooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 - 39
Part Number Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Restriction on the use of Hazardous Substances
(RoHS)
At Tyco Electronics, we’re ready to support your RoHS require-
ments. We’ve assessed more than 1.5 million end items/com-
ponents for RoHS compliance, and issued new part numbers
where any change was required to eliminate the restricted mate-
rials. Part numbers in this catalog are identified as:
RoHS Compliant
— Part numbers in this catalog are RoHS
Compliant, unless marked otherwise. These products comply
with European Union Directive 2002/95/EC as amended 1
January 2006 that restricts the use of lead, mercury, cadmium,
hexavalent chromium, PBB, and PBDE in certain electrical and
electronic products sold into the EU as of 1 July 2006.
NOTE: For purposes of this Catalog, included within the defini-
tion of RoHS Compliant are products that are clearly “Out of
Scope” of the RoHS Directive such as hand tools and other
non-electrical accessories.
NOTE: Information regarding RoHS compliance is provided
based on reasonable inquiry of our suppliers and represents our
current actual knowledge based on the information provided by
our suppliers. This information is subject to change. For latest
compliance status, refer to our website referenced at right.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
Getting the Information You Need
Our comprehensive on-line RoHS Customer Support Center
provides a forum to answer your questions and support your
RoHS needs. A RoHS FAQ (Frequently Asked Questions) is
available with links to more detailed information. You can also
submit RoHS questions and receive a response within 24 hours
during a normal work week. The Support Center also provides:
■
Cross-Reference from
Non-compliant to Compliant
Products
■
Ability to browse RoHS
Compliant Products in our
on-line catalog
■
Downloadable Technical Data
Customer Information
Presentation
■
More detailed information
regarding the definitions used above
■
So whatever your questions when it comes to RoHS,
we have the answers at www.tycoelectronics.com/leadfree
RoHS
Customer
Support
Center
See inside back cover for Global
Contacts and phone numbers.
