Part Number:
Status:
Overview:
Description:
0051260000
Active
LFH™ Interconnect System
1.90mm Pitch LFH ™ Matrix 75 Shielded Receptacle, 96 Circuits, Right Angle, Bright
Nickel (Ni) Finish, 2.34mm PC Tail Length
Documents:
3D Model
Drawing (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
Component Type
Overview
Product Name
Type
UPC
Physical
Boot Color
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Color - Resin
Flammability
Gender
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Ports
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Product Specification PS-70660 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
LR19980
E29179
I/O Connectors
70660
Board-to-Board, Wire-to-Board
Receptacle
LFH™ Interconnect System
LFH™
N/A
800754387682
N/A
96
96
96
Black
94V-0
Receptacle
None
Yes
Beryllium Copper
Gold
Tin-Lead
High Temperature Thermoplastic
22.997/g
4
Right Angle
2.34mm
No
None
1.57mm
Tube
Yes
1.90mm
1.90mm
0.762µm
2.540µm
Yes
No
1
Yes
-20°C to +80°C
Through Hole
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/21/2016 (20 June
2016)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
70660 Series
Mates With
70665 , 71995
Use With
71628 Guide Pin, Guide Sleeve 71629 or
71771, 70982 Hex Screw Kit
Waterproof / Dustproof
Wire Size AWG
Electrical
Current - Maximum per Contact
Grounding to Panel
Shield Type
Shielded
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Engineering Number
Reference - Drawing Numbers
Product Specification
Sales Drawing
No
N/A
1.0A
None
Full Shield
Yes
40V AC (RMS)
040
SMC&WAVE
003
245
706600001
PS-70660
SDA-70660-0001
