ZPSA40/60 Series
40-60W, 2 x 4” AC-DC Power Supplies
Features
Single Output
Wide Range AC Input
Low 1.07” profile
Industry Standard Footprint
Global Safety Agency Compliance
Up to 88% efficiency
Key Market Segments & Applications
Specifications
Model
Input Voltage range
Inrush Current (115 / 230VAC)
Input Current
Leakage Current
Temperature Coefficient
Voltage Accuracy
Minimum Load
Load Regulation
Line Regulation
Ripple & Noise
Short Circuit Protection
Overvoltage Protection
Hold Up Time (Typ)
LED Indicator
Operating Temperature
Storage Temperature
Humidity (non condensing)
Cooling
Withstand Voltage
Isolation Resistance
Vibration (non operating)
Shock
Safety Agency Certification
Conducted & Radiated EMI
Immunity
Weight (Typ)
Size (WxLxH)
Warranty
-
A
A
mA
-
%
-
%
%
mV
-
V
ms
-
°C
°C
-
-
-
-
-
-
-
-
-
g
in
yrs
ZPSA40
ZPSA60
90 - 264VAC (47 - 440Hz) or 120 - 370VDC*
25 / 50
< 1.2A
< 1.4A
0.8mA maximum (264VAC, 60Hz)
±0.05%/°C
±1%
None
±1%
±0.5%
1% or 50mV whichever is greater
Continuous - hiccup mode
Typically 110-130% of nominal
8ms at 115VAC input
Green LED = OK
0 to +70°C derate according to charts on page 2
-20 to +85°C
10 - 95% RH
Convection
Input to Ground 1.5kVAC, Input to Output 3kVAC, Output to Ground 500VAC for 1 min.
>100M at 25C & 70%RH, Output to Ground 500VDC
-23.52m/s
2
(10 - 55Hz: constant sweep 1 min X, Y, Z for 1 hour)
< 196.1 m/s
2
(20G)
UL60950-1, CSA60950-1, EN60950-1, CE Mark
EN55022-B, FCC Class B
EN61000-4-2, -3, -4, -5, -6, -8, -11
130
2 x 4 x 1.07 (including underside components)
Two Years
*Safety certified for 47-63Hz input only
1-800-526-2324 • www.us.tdk-lambda.com/lp/
83
Disclaimer: us.tdk-lambda.com/lp/legal.htm
ZPSA40/60 Series
Model Selector
Model
ZPSA40-3R3
ZPSA60-3R3
ZPSA40-5
ZPSA60-5
ZPSA40-9
ZPSA60-9
ZPSA40-12
ZPSA60-12
ZPSA40-15
ZPSA60-15
ZPSA40-24
ZPSA60-24
ZPSA40-28
ZPSA60-28
ZPSA40-30
ZPSA60-30
ZPSA40-36
ZPSA60-36
ZPSA40-48
ZPSA60-48
Output (V)
3.3
3.3
5
5
9
9
12
12
15
15
24
24
28
28
30
30
36
36
48
48
Adjustment
Range (V)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Maximum
Output (A)
6.0
8.0
6.0
8.0
4.45
6.67
3.34
5.0
2.67
4.0
1.67
2.5
1.43
2.14
1.33
2.0
1.11
1.67
0.834
1.25
Peak
Load (A)(4)
7.2
8.5
7.2
9.0
5.34
8.0
4.0
6.0
3.2
4.8
2.0
3.0
1.7
2.6
1.6
2.4
1.33
2.0
1.0
1.5
Output
Power (W)
20
26
30
40
40
60
40
60
40
60
40
60
40
60
40
60
40
60
40
60
Efficiency
(%)
74
74
79
79
83
83
85
85
85
85
86
86
86
86
86
86
87
86
87
87
(4) Average not to exceed max power, <30s, 10% duty cycle
Derating Curve
ZPSA40 -3 -5 -9 -12
ZPSA60 -3 -5 -9 -12
Outline Drawings
ZPS40
-
-15
24 -28
-28
3
-30 -36 -48
ZPSA40 15 -
-24
-30 - 6 -48
ZPS60 -15 -24 -28 -30 -36 -48
ZPSA60 -15 -24 -28 -30 -36 -48
Other Industrial Products
SC40/60
NV175
ZWS
KPSA
ZPD, ZPT
40 to 80W, 3x5”, 1 - 3 outputs
175W, 3x5”, 1-5 outputs
5 to 240W, single output
5 to 15W, pcb mount
40W, 2x4” dual and triple outputs
Options
Suffix
Blank
/P
Description
Molex connectors
PCB mount pins
For Additional Information, please visit
us.tdk-lambda.com/lp/products/zpsa-series.htm
1-800-526-2324 • www.us.tdk-lambda.com/lp/
84
Revision A9: Aug 2015
