AC-DC Power Supplies Open Frame/Enclosed type
Ordering information
LCC30A
R
LC
1
2
C
3
30
4
A
5
-1
6
-O
1Series
name
2Multiple
output
3Output
wattage
4100/120V
input
5Output
voltage combina-
tion
6Optional
*6
A :G2 - V3 Common
C :with Coating
G :Low leakage current
Y :with Potentiometer
MODEL
DC OUTPUT
V1
V2
V3
*
1
LCC30A-1
5V 3.0(Peak 4.5)A
12V 1.2(Peak 2.0)A
12V 0.3(Peak 0.45)A
LCC30A-2
5V 3.0(Peak 4.5)A
15V 1.0(Peak 2.0)A
15V 0.3(Peak 0.45)A
LCC30A-3
5V 3.0(Peak 4.5)A
24V 0.5(Peak 1.3)A
5V 0.5(Peak 0.75)A
LCC30A-4
3.3V 4.0(Peak 6.0)A
12V 1.2(Peak 2.0)A
5V 0.5(Peak 0.75)A
SPECIFICATIONS
MODEL
VOLTAGE[V]
ACIN 100V
CURRENT[A]
FREQUENCY[Hz]
EFFICIENCY[%]
ACIN 100V
INRUSH CURRENT[A] ACIN 100V
LEAKAGE CURRENT[mA]
VOLTAGE[V]
*
2
CURRENT[A]
LINE REGULATION[mV]
LOAD REGULATION[mV]
0 to +50
C
*
3
RIPPLE[mVp-p]
-10 - 0
C
*
3
0 to +50
C
*
3
RIPPLE NOISE[mVp-p]
-10 - 0
C
*
3
0 to +50
C
TEMPERATURE REGULATION[mV]
-10 to +50
C
*
4
DRIFT[mV]
START-UP TIME[ms]
HOLD-UP TIME[ms]
OUTPUT VOLTAGE ADJUSTMENT RANGE[V]
*
5
OUTPUT VOLTAGE SETTING[V]
OVERCURRENT PROTECTION
OVERVOLTAGE PROTECTION
OPERATING INDICATION
REMOTE SENSING
REMOTE ON/OFF
INPUT-OUTPUT
INPUT-FG
OUTPUT-FG
OUTPUT-OUTPUT(V1,V2,V3)
OPERATING TEMP.,HUMID.AND ALTITUDE
STORAGE TEMP.,HUMID.AND ALTITUDE
VIBRATION
IMPACT
AGENCY APPROVALS
CONDUCTED NOISE
CASE SIZE/WEIGHT
COOLING METHOD
LCC30A-1
LCC30A-2
LCC30A-3
LCC30A-4
AC85 - 132 1
f
or DC110 - 170
0.8typ (Io=100%)
47 - 440 or DC
72typ (Io=100%)
67typ (Io=100%)
(Io=100%) (At cold start)
25typ
0.5 max (60Hz, by UL and DEN-AN)
5
12
12
5
15
15
5
24
5
3.3
12
0 - 3.0(Peak 4.5) 0 - 1.2(Peak 2.0) 0 - 0.3(Peak 0.45) 0 - 3.0(Peak 4.5) 0 - 1.0(Peak 2.0) 0 - 0.3(Peak 0.45) 0 - 3.0(Peak 4.5) 0 - 0.5(Peak 1.3) 0 - 0.5(Peak 0.75) 0 - 4.0(Peak 6.0) 0 - 1.2(Peak 2.0)
20max 48max 48max 20max 60max 60max 20max 100max 20max 20max 48max
100max 120max 150max 100max 120max 150max 100max 150max 100max 40max 120max
100max 120max 120max 100max 120max 120max 100max 120max 120max 80max 120max
150max 160max 160max 150max 160max 160max 150max 160max 160max 140max 160max
120max 150max 150max 120max 150max 150max 120max 150max 150max 120max 150max
170max 180max 180max 170max 180max 180max 170max 180max 180max 160max 180max
50max 350max 350max 50max 350max 350max 50max 480max 350max 50max 350max
60max 420max 420max 60max 420max 420max 60max 580max 420max 60max 420max
20max
xx
20max
xx
20max
xx
20max
xx
xx
xx
xx
(ACIN 85V, Io=100%)
100max
10typ (ACIN 85V, Io=100%) , 20typ (ACIN 100V, Io=100%)
Fixed
Fixed
Fixed
Fixed
Fixed
Fixed
Fixed
Fixed
Fixed
3.00 - 3.60 Fixed
4.9 to 5.3 11.4 to 12.6 11.4 to 12.6 4.9 to 5.3 14.25 to 15.75 14.25 to 15.75 4.9 to 5.3 22.8 to 25.2 4.75 to 5.25
xx
11.4 to 12.6
Works over 105% of rating and recovers automatically
Works at 115 - 140% of rating (V1 only)
Not provided
Not provided
Not provided
AC2,000V 1minute, Cutoff current = 10mA, DC500V 50M
W
min (At Room Temperature)
AC2,000V 1minute, Cutoff current = 10mA, DC500V 50M
W
min (At Room Temperature)
AC500V 1minute, Cutoff current = 100mA, DC500V 50M
W
min (At Room Temperature)
AC100V 1minute, Cutoff current = 100mA, DC100V 10M
W
min (At Room Temperature)
-10 to +60
C
, 20 - 90%RH (Non condensing), 3,000m (10,000feet)
-20 to +75
C
, 20 - 90%RH (Non condensing), 9,000m (30,000feet)
10 - 55Hz, 19.6m/s
2
(2G), 3minutes period, 60minutes each along X, Y and Z axis
196.1m/s
2
(20G), 11ms, once each X, Y and Z axis
UL60950-1, C-UL Complies with DEN-AN (At only AC input)
Complies with FCC-B, VCCI-B
65
X
26
X
120mm (W
X
H
X
D) / 170g max
Convection
INPUT
LCC
OUTPUT
5
0 - 0.5(Peak 0.75)
20max
100max
120max
160max
150max
180max
350max
420max
xx
Fixed
4.75 to 5.25
PROTECTION
CIRCUIT AND
OTHERS
ISOLATION
ENVIRONMENT
SAFETY AND
NOISE
REGULATIONS
OTHERS
*1
Because V2 - V3 is isolated,V3 can be as used -VOUT.
*2
Peak load for 10sec. or less is acceptable if the peak total wattage is less than the rated
wattage(-1: 33W, -2: 34.5W, -3: 34.5W, -4: 34.5W).When the load of V1 is 0A, other output
can be drawn by 80% of rated current.
*3
Measured by 20MHz oscilloscope or Ripple-Noise meter (equivalent to KEISOKU-
GIKEN:RM101).
*4
Drift is the change in DC output for an eight hour period after a half-hour warm-up at 25C
with the input voltage held constant at the rated input/output.
*5
Adjustment of output voltage for V1 (+5V+5%) is possible (Optional).
Please refer to 2.5 minimum output current and 4.2 derating.
*6
Please contact us about safety approvals for the model with option.
*
Avoid prolonged use under over-load.
LCC-2
