Uninterruptible Power Supplies
Section 20
Power dependency has increased dramatically in the new
business environment based on e-commerce applications,
mobile networks, corporate Internet sites, e-pay and networked
IT structures. Near one-hundred percent system availability is
mandatory in view of the financial and business consequences.
Not only does the absence of power have catastrophic
consequences, but also an unnoticed mains disturbance can
affect your expensive equipment or critical processes. Power
Quality Products are designed to reduce customer risks to
power issues.
Power Quality Services ..............................................................20-2
Digital Energy™ VCL Series.......................................................20-4
Digital Energy™ VH Series (700-2000 Rackmount and/or Tower)
Description, Applications, Features and Benefits .....................20-5
Technical Specifications and Dimensions....................................20-6
Product Tables – UPS and Battery Packs......................................20-7
Digital Energy™ GT Series 120 V (3000 VA Tower)
Description, Applications, Features and Benefits...................20-10
Technical Specifications and Dimensions .................................20-11
Product Tables – UPS...........................................................................20-11
Digital Energy™ GT Series 120 V (3000 19" Rackmount)
Description, Applications, Features and Benefits...................20-12
Technical Specifications and Dimensions .................................20-13
Product Tables – UPS and Battery Packs...................................20-13
Digital Energy™ GT Series (5kVA and 6kVA Tower/Rackmount)
Description, Features and Benefits...............................................20-14
Technical Specifications and Dimensions .................................20-15
Product Tables – UPS and Battery Packs...................................20-16
Digital Energy™ GT Series (8kVA and 10kVA Tower/Rackmount)
Description, Features and Benefits...............................................20-17
Technical Specifications and Dimensions .................................20-18
Product Tables – UPS and Battery Packs...................................20-19
Digital Energy™ LP11U Series 208 V (Single-Phase 5-10 kVA)
Description, Features and Benefits...............................................20-20
Technical Specifications and Dimensions .................................20-21
Product Tables – UPS and Battery Packs...................................20-22
Digital Energy™ LP33U Series 208 V (Three-Phase 10-100 kVA)
Description, Features and Benefits...............................................20-24
Technical Specifications and Dimensions .................................20-25
Product Tables – UPS and Battery Cabinets.............................20-26
Digital Energy™ SG Series 480 V (Three-Phase 10-750 kVA)
Description, Features and Benefits...............................................20-31
Technical Specifications and Dimensions (10-150 kVA)......20-33
Product Tables (10-150 kVA) –UPS, Battery Cabinets,
Transformers and Bypass Panels...............................................20-33
Technical Specifications and Dimensions (225-300 kVA) ...20-40
Product Tables (225-300 kVA) ) –UPS, Battery Cabinets,
Transformers and Bypass Panels..............................................20-40
Technical Specifications and Dimensions (400-500 kVA)......20-43
Product Tables (400-500 kVA) –UPS, Battery Cabinets,
Transformers and Bypass Panels..............................................20-43
Software and Connectivity Products (10-500 kVA) ................20-45
Spare Parts, Options and Accessories (10-500 kVA) .............20-46
Services and Commissioning (10-500 kVA)...............................20-47
Digital Energy™ TLE Series (225-1500 kW)
Description, Features and Benefits...............................................20-48
Rev. 11/13
Data subject to change
without notice
www.geindustrial.com
BuyLog
™
Catalog
20-1
Uninterruptible Power Supplies
Power Quality Services for the Digital World
Section 20
Delivering Critical Power Reliability
Improved Reliability for the Entire Site
Facilities with critical power infrastructure need to maintain
a constant supply of clean and reliable power that will keep
business operating at all times.
To help protect your entire electrical infrastructure—from
the utility meter and the UPS to the critical load—GE offers a
comprehensive array of services that can ensure continuous
operation of controls and equipment during a power loss.
Without an effective diagnostics and maintenance program,
critical power system components (such as battery systems)
are prone to failure.
Uninterrupted Revenue Stream
To avoid potential loss of revenue streams from unplanned outages,
GE designed a preventive maintenance program that can be
customized to meet the specific needs of your site. The program
also reduces long-term maintenance cost and capital expenditures.
Single Point of Contact with Worldwide Sourcing
Operating from a worldwide network of service centers with a
large critical parts inventory, our highly trained repair specialists
work at a schedule that accommodates your site needs. With
extensive experience across multiple brands of equipment,
they can free your plant personnel to focus on their core
competencies. In order to ensure an effective and rapid response,
GE provides a single point of contact to coordinate all of your
service needs.
Expert Inspection and Maintenance Services
With an average of five years of in-depth experience on
equipment across the industry, GE specialists have the required
range of skills to protect your operation from power interruptions.
Expert interpretation of inspection data allows our engineers to
provide you with the preventive or corrective services that are
most appropriate for your business, including:
—Inspection
Services
Review customer maintenance logs; perform
safety checks; visually inspect power equipment, batteries and
rectifiers; provide detailed reports with findings and recommendations.
—Uninterruptible
Power Supply (UPS) Preventive Maintenance
Services
Verify equipment functionality and provide detailed
reports with findings and recommendations for GE and multi-
vendor systems.
—Rectifier
Preventive Maintenance Services
Verify operation of
all rectifiers/chargers; read and record DC float voltage; read and
record AC input voltage and current; and calibrate panel meters.
—Remedial
Services
Test and repair UPS, rectifier and related
critical power equipment.
—Remote
Monitoring and Diagnostics (RM&D)
Advanced
algorithms for data analysis and condition assessment; performance
trending; diagnostics/problem assessment; rapid response for
emergency troubleshooting and addressing technical questions.
—Engineering
Services
Design-build services for ISP facilities;
technical and logistical support for multi-vendor equipment and
site analysis for power problems (UPS, generator interfacing,
harmonics or power fluctuations).
—Site
Monitoring
Moderate cost, high performance system
incorporates monitoring logging, alarming and a multi-protocol
notifying system. GE-monitored alarm management response
program.
—Complete
Spare Parts Inventory
Worldwide sourcing
capability provides UPS, batteries (VRLA and flooded), DC
equipment, replacement boards and components for UPS and
DC equipment.
—Critical
Power Equipment Operator Training
Hands-on
classroom or on-site training to increase operator reliability
and accuracy.
—Battery
Preventive Maintenance Services
Measure and record
cell float voltage, the specific gravity on all flooded cells and cell
conductance to determine the relative state of health for VRLA
battery types. Adjust float and equalize voltage settings to
manufacturer specific values. Record electrolyte temperature on
flooded cells and record temperatures on the negative post (on
VRLA battery types). Inspect terminals, cables, and hardware;
cell elements; battery racks, cell covers and post seals.
Benefits
—Greater reliability
—Reduced outages and risk of lost revenues
—Lower capital expenditures and maintenance costs
—Single point of contact for all services
Reliability Services
—UPS commissioning and upgrades
—Battery installation and maintenance
—Battery replacement
—System stability and reliability consulting
—Remote monitoring and diagnostics (RM&D)
—Infrared thermal imaging
—Asset management services
Critical Parts Availability
—Worldwide critical spare parts inventory and servicing
—Continually updated database for most efficient sourcing
—Global emergency service with rapid response times to meet
your critical needs
—Depot repair staff available to ensure reliability of your electrical
infrastructure
—Operator training on a variety of multi-vendor power equipment
(on-site or at a GE location)
20-2
BuyLog
™
Catalog
www.geindustrial.com
Rev. 11/13
Data subject to change
without notice
Uninterruptible Power Supplies
Power Quality Services for the Digital World
Section 20
Increased Reliability of Critical Power Systems
GE’s expertise can help deliver critical power for continuous
operations.
Our comprehensive array of services ensures the reliability of
critical power battery and rectifier/charging systems when they
are needed most. While battery systems are the most crucial
components of a critical power system, they can be prone
to failure—unless an effective diagnostics and maintenance
program is in place.
Uninterrupted Revenue Stream
To prevent potential loss of revenue streams from unplanned
outages, GE has designed a preventive maintenance program
tailored to the Transmission and Distribution needs of Independ-
ent Power Providers, Investor Owned Utilities (IOUs), Non-Utility
Generator (NUGs), and municipal and industrial power providers.
In addition to providing reliable power in substations and generat-
ing plants, the program also reduces long-term maintenance cost
and capital expenditures.
Single Point of Contact with Worldwide Sourcing
Operating from a worldwide network of service centers with a
large critical parts inventory, our highly trained specialists work
at a schedule that accommodates your site needs. With extensive
experience across multiple brands of equipment, they can free
your plant personnel to focus on core competencies. In order to
ensure an effective and rapid response, GE provides a single point
of contact to coordinate all of your service needs.
Expert Inspection and Maintenance Services
GE specialists have the required range of skills to protect your
operation from power interruptions. Expert interpretation of
inspection data allows our engineers to provide you with the
preventive or corrective services that are most appropriate
for your business, including:
—Inspection
Services
Review customer maintenance logs;
perform safety checks; visually inspect power equipment,
batteries and rectifiers; provide detailed reports with findings
and recommendations.
—Asset
Management Services
Develop and maintain asset
inventories.
—Battery
Preventive Maintenance Services
Measure and
record cell float voltage; the specific gravity on all flooded cells
and cell conductance to determine the "relative" state of health
for VRLA battery types. Adjust float and equalize voltage
settings to manufacturer specific values. Record electrolyte
temperature on flooded cells and record temperatures on
the negative post (on VRLA battery types). Inspect terminals,
cables, and hardware; cell elements; battery racks; cell covers
and post seals.
—Rectifier
Preventive Maintenance Services
Verify operation
of all rectifiers/chargers; read and record DC float voltage;
read and record AC input voltage and current and calibrate
panel meters.
—Remedial
Services
Clean and correct all corroded connections;
replenish low electrolyte fluid levels (flooded cells only) and
apply single unit charge techniques to re-establish string
balance.
—Battery
Replacement Services
Install, inspect, test clean and
repair of battery systems as well as removal/replacement using
EPA registered and approved recyclers.
Benefits
—Greater reliability
—Reduced outages and risk of lost revenues
—Single Point of Contact
—Lower capital expenditures and maintenance costs
—Reduced safety risk
—Single point of contact for all services
—EPA compliant battery recycling
Applicable Markets
—Commercial
—Healthcare
—Utility
—Information Technology
—Defense
—Industrial
Critical Parts Availability
—Worldwide critical parts inventory
—Rapid access database for most efficient sourcing
—Depot repair staff available to ensure reliability of Transmission
and Distribution networks
For Emergency Service call: 1-800-637-1738
Rev. 11/13
Data subject to change
without notice
www.geindustrial.com
BuyLog
™
Catalog
20-3
Uninterruptible Power Supplies
Digital Energy™ VCL Series
800 - 3000 VA
GE’s new line interactive pluggable range of UPS, the VCL Series UL,
is available in tower and/or rack format, 2U high across all ratings.
The UPS is a high performance range available in 800VA, 1100VA,
2000VA and 3000VA.
Please contact your sales representative or refer to the website for
further details.
Section 20
20-4
BuyLog
™
Catalog
www.geindustrial.com
Rev. 11/13
Data subject to change
without notice
Uninterruptible Power Supplies
Digital Energy™ - VH Series
VH700 - 1000 - 1500 – 2000 UL
Description
GE’s VH Series Uninterruptible Power Supply (UPS) connects be-
tween the utility and your critical load, helping ensure that when
the utility drops or fails, your load continues to receive a clean,
constant and reliable power supply. The VH Series UPS is ideal for
protection against utility variances and failures for PC, telecom,
laboratory, industrial and critical process loads.
The VH Series is a true Voltage and Frequency Independent (VFI)
on line, double conversion UPS providing secure power for busi-
ness-critical applications. With a tower and/or rack mount design,
the UPS adapts to adjusting network configurations as facility
load requirements change. Delivering 0.9 output power factor, a
Mean Time Between Failure (MTBF) of 730,000 hours and a three
year warranty standard on UPS and battery, the user can be as-
sured of a high performance, high power and highly reliable level
of power protection.
Applications
The VH Series UPS is ideal for both standard and non-standard
network IT environments including:
—PCs and servers
—CCTV and security systems
—Telecom
—Railway signaling
—Small to midsized networks
—Laboratory analysis equipment
—Process control
—Wind turbine pitch controls
Features and Benefits
Section 20
—Unique failsafe internal bypass - Continued operation even with
overload or over-temperature
—2U design for all ratings - Small footprint; parts supplied for
tower or rack assembly
—Hot swappable batteries - Simple, fast battery replacement
without disruption to the load
—Matching battery cabinets - Longer battery life available with
the addition of extra battery cabinet(s)
—Superior battery management – Provides protection to the
battery and extends the battery life
—Remote monitoring - Easy access and control even for
unmanned or isolated sites
—MTBF >730,000 hours - Proven reliability
—Increased power handling - 0.9 output power factor delivers
more actual power to the load
—Reliability
—Voltage and Frequency Independent (VFI) double conversion
—Failsafe bypass
—Comprehensive warranty and high MTBF
—Continuity
—Automatic bypass switch
—Easy, fast battery replacement
—Large charge capacity and boost/float charging
—Flexibility
—Tower and rackmount, small footprint
—Unique high peak load handling
—Frequency converter
—Compatibility
—High output power factor (0.9)
—Standard USB connection
—Range of communication options
Rev. 11/13
Data subject to change
without notice
www.geindustrial.com
BuyLog
™
Catalog
20-5
京公网安备 11010802033920号
EEWORLD
