Material
Plating
Wire Size
Wire Type
High Conductivity
Seamless Copper Tube
Electro-Tin
1.28±.04
PANDUIT
250 STR/FLEX
LCCX250-14BF
250 STR/FLEX
Stranded Copper:
Class G, H, I, K, M,
Locomotive
2-5/16 in.
1/4 in.
Yes, for applications up to 35kv.
Consult cable manufacturer for
voltage stress relief instructions
with applications greater than
2000 volts.
90 C
Yes
YELLOW
Wire inspection
window
Wire Strip Length
Stud Size
UL Listed Wire
Connector
.25±.04
.75±.02
.27±.02 DIA
(2) PLS
1.34±.04
UL Temperature
Rating
C.S.A Certified
Wire Connector
Panduit Color Code
on Barrel
.17±.01
90°±5°
3.23
REF
2.24±.04
YELLOW DIE P62 (16)
PANDUIT
Panduit Die Index No. P62
on Barrel
Alternate Industry
Die Index No. ( )
on Barrel
(16)
.70±.01
CERTIFIED
LISTED
Wire Connector
.88±.01
2.46 REF
Beveled wire
entry
Color coded
barrel markings
CORP.
00
REV
TINLEY PARK, ILLINOIS
6/03
DATE
SAC SAC
BY
CHK
RELEASED
DESCRIPTION
10850
ECN
LCCX250-14BF-X
Copper Lug - Two-Hole, Long Flex Barrel with Window, 90° Angle Tongue
SCALE
N/A
DRAWING NO / CAD FILE
LCCX250-14BF-CUST
