K88X-CD-37S-BRJ: DescriptionD-Sub Standard Connectors D37F VERT HIPROF FRM W/BRD LCK J/S; CategoryThe connector The connector; File Size485KB，1 Pages; ManufacturerKycon; Environmental Compliance

Download Datasheet Parametric View All

K88X-CD-37S-BRJ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	K88X-CD-37S-BRJ	-	-	View	Buy Now

K88X-CD-37S-BRJ Overview

D-Sub Standard Connectors D37F VERT HIPROF FRM W/BRD LCK J/S

K88X-CD-37S-BRJ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Kycon
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Body/casing type	RECEPTACLE
Connector type	D SUBMINIATURE CONNECTOR
Contact to complete cooperation	GOLD FLASH
Contact completed and terminated	GOLD FLASH
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	K88X
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	BOARD
Options	GENERAL PURPOSE
Housing size	4/C
Termination type	SOLDER
Total number of contacts	37

Preview

Download Datasheet

View All

2D Drawing

Solder Profile

Certificate of Origin

IGES

CofC RoHS Compliant

Check Stock

STEP

CofC REACH Compliant

Request a Sample

3D PDF

UL Plastic File

Send Us An Email

Generated Part Number

K88X-ED-9P

Part Number Builder

LR78160

D-SUBMINIATURE CONNECTORS:

K88X

Series

Vertical PCB Mount High Profile

K88X Series

Dimensions

Dimensions in mm

C

B

K88X

Series

E

Shell

Type

D

Type

9

Contact

Option

P

Contact

Type

Mounting

Option

Series

K88X

-

D-SubminiatureVertical Connector

Contact Shell Size

E

- 9 Contacts

A

- 15 Contacts

B

- 25 Contacts

C-

37 Contacts

8.36 Plug Interior,

7.90 Socket Exterior

2.77

2.84

A, A1

12.55

6.1 Plug,

5.8 Socket

10.98 Max.

Pin Type (L1)

D

- 3.80mm

Contact Type

P

- Pin Contact (Plug)

S

- Socket Contact (Receptacle)

Mounting Option

Blank

- Through Hole

BR

- #4-40 Tin Plated 11.00mm Long Boardlocks

BRJ

- #4-40 Boardlocks and #4-40 Jackscrews

K

- #4-40 Bushings

KJ

- #4-40 Bushings and #4-40 Jackscrews

Contact Kycon for plating and Other Options

0.9

L1

1.385

D

10.72

±0.25

2.84

Number

of Contacts

(Shell Size)

9 (E)

15 (A)

25 (B)

37 (C)

Dimensions ( mm )

A

16.33

24.66

38.38

54.84

A1

16.92

25.25

38.96

55.42

B

24.99

33.32

47.04

63.50

C

30.81

39.14

53.04

69.32

D

19.18

27.51

41.00

57.71

A = Exterior of Female Shell (S)

A1 = Interior of Male Shell (P)

Phone: +1.408.494.0330

l

Fax: +1.408.494.0325

l

WWW.KYCON.COM

l

2013
