CRYSTAL OSCILLATOR
Low Profile / High stability SPXO
SG - 150 S*E
Frequency
range
:
Supply
voltage
:
Current
consumption
:
Function
External
dimensions
:
:
3.000 MHz to 54.000 MHz
1.8 V / 2.5 V / 3.3 V
1.2 mA Typ.
(SEE: 1.8 V No load condition 40 MHz)
Standby(
ST
)
2.1 × 1.7 × 0.75 mm
Actual size
Specifications (characteristics)
Item
Output frequency range
Supply voltage
Storage temperature
Operating temperature
Frequency tolerance *
Symbol
SG-150SEE
1.8 V Typ.
1.6 V to 2.2 V
Specifications
SG-150SDE
3.000 MHz to 54.000 MHz
2.5 V Typ.
-40
C
to +85 °C
-40
C
to +85 °C
-6
-6
D:
20
× 10 , E:
15
× 10
-6
-6
H:
20
× 10 , T:
15
× 10
2.5 mA Max.
3.0 mA Max.
3.5 mA Max.
5.0 mA Max.
5.0 µA Max.
45 % to 55 %
90 % V
CC
Min.
10 % V
CC
Max.
15 pF Max.
80 % V
CC
Min.
20 % V
CC
Max.
4.5 ns Max.
5 ms Max.
2.2 V to 2.7 V
SG-150SCE
3.3 V Typ.
2.7 V to 3.6 V
Conditions / Remarks
Please contact us for inquiries regarding
the available frequencies.
Store as bare product.
-20
C
to +70
C
V
CC
10%
-40
C
to +85
C
No load condition,3 MHz≤f
0
32
MHz
No load condition,32 MHz<
f
0
40
MHz
No load condition,40 MHz<
f
0
48
MHz
No load condition,48 MHz<
f
0
54
MHz
ST
=GND
50 % V
CC
level,L_CMOS
15 pF
I
OH
=-4 mA
I
OL
= 4 mA
f
0
V
CC
T_stg
T_use
f_tol
2.3 mA Max.
2.8 mA Max.
3.3 mA Max.
4.5 mA Max.
Current consumption
Stand-by current
Symmetry
Output voltage
Output load condition
(CMOS)
Input voltage
Rise time / Fall time
Start-up time
Frequency aging
I
CC
I_std
SYM
V
OH
V
OL
L_CMOS
V
IH
V
IL
3.5 mA Max.
4.0 mA Max.
4.5 mA Max.
6.0 mA Max.
ST
terminal
t
r
/
t
f
t
_
str
f_aging
This is included in frequency tolerance specification.
20 % V
CC
to 80 % V
CC
level,
L_CMOS=15 pF
t=0 at 90 % V
CC
+25 °C, First year,
V
CC
= 1.8 V, 2.5 V, 3.3 V
(Unit:mm)
* Please contact us for inquiries regarding available frequency tolerance.
External dimensions
2.10.1
#6
#5
#4
1.70.1
#4
#5
C0.15
#3
#3
0.750.05
Pin map
Pin
1
2
3
4
5
6
#2
0.405
(Unit:mm)
0.45
Footprint (Recommended)
0.54 0.48
26ABCD
●
6789A
#1
#2
#6
C
(ex. 0.01 µF)
Resist
0.6
#4
0.75
1.13
#1
1.65
To maintain stable operation, provide a 0.01uF to
0.1uF by-pass capacitor at a location as near as
possible to the power source terminal of the crystal
product (between Vcc - GND).
#1
0.25
#6
Connection
ST
Note.
ST pin = HIGH : Specified frequency output.
ST pin = LOW : Output is high impedance, oscillation stops.
TEST pin : Do not connect externally.
(Recommend the design without the footprint.)
(TEST)
GND
OUT
(TEST)
V
CC
#3
