Type DPP
Polypropylene Radial Leaded Film Capacitors
High Frequency
Precise Values
Film/Foil
Radial Leaded
Type DPP
radial leaded polypropylene flm/foil
capacitors are non-inductively wound. Very low
dissipation factor and high insulation resistance con-
tribute to excellent performance and long-term sta-
bility characteristics. Low ESR, DF and its inherent
stability make
Type DPP
an ideal choice for tight tol-
erance, pulse and high-frequency applications.
Specifcations
Capacitance Range:
0.001 to 0.47 µF
Voltage Range:
100 to 630 Vdc
(70 to 250 Vac, 60 Hz)
Capacitance Tolerance:
±10% standard,
±5% optional
Operating Temperature Range:
–55 ºC to +105 ºC*
Pulse Capability
Body Length
Rated
Volts
100
250
400
630
0.630
4200
6900
19000
60000
.790 - .940
4000
4100
10000
20000
≥1.02
1900
2400
3200
6700
NOTE: Other capacitance values, sizes and performance specifications
are available. Please contact CDE.
Dielectric Strength:
200% (1 minute)
Dissipation Factor:
0.10% Max. (+25 ºC, 1 kHz)
Insulation Resistance:
50,000 MΩ·µF,
100,000 MΩ Min.
Life Test:
1000 hr at 85 ºC at 125% rated voltage
*Full rated voltage at 85 ºC, derated linearly to 50% rated voltage at +105 ºC
RoHS Compliant
dV/dt — volts per microsecond, max.
Ratings
Catalog
Cap
(µF)
.033
.047
.068
.10
.15
.22
.33
.47
.010
.015
.022
DPP1S33K-F
DPP1S47K-F
DPP1S68K-F
DPP1P1K-F
DPP1P15K-F
DPP1P22K-F
DPP1P33K-F
DPP1P47K-F
DPP2S1K-F
DPP2S15K-F
DPP2S22K-F
Part Number
T Max.
Inches (mm)
0.315 (8.0)
0.335 (8.5)
0.374 (9.5)
0.394 (10.4)
0.433 (11.0)
0.512 (13.0)
0.551 (14.0)
0.630 (16.0)
0.276 (7.0)
0.295 (7.5)
0.315 (8.0)
H Max.
Inches (mm)
0.532 (13.5)
0.610 (15.5)
0.650 (16.5)
0.670 (17.0)
0.748 (19.0)
0.748 (19.0)
0.827 (21.0)
0.945 (24.0)
0.473 (12.0)
0.473 (12.0)
0.512 (13.0)
L Max.
Inches (mm)
0.768 (19.5)
0.768 (19.5)
0.788 (20.0)
1.024 (26.0)
1.024 (26.0)
1.024 (26.0)
1.260 (32.0)
1.260 (32.0)
0.591 (15.0)
0.591 (15.0)
0.591 (15.0)
S ±0.06 (±1.5)
Inches (mm)
0.591 (15.0)
0.591 (15.0)
0.591 (15.0)
0.788 (20.0)
0.788 (20.0)
0.788 (20.0)
1.083 (27.5)
1.083 (27.5)
0.394 (10.0)
0.394 (10.0)
0.394 (10.0)
d ±0.05 (1.27)
Inches (mm)
.024 (.6)
.024 (.6)
.024 (.6)
.024 (.6)
.032 (.8)
.032 (.8)
.032 (.8)
.032 (.8)
0.024 (.6)
0.024 (.6)
0.024 (.6)
100 Vdc (70 Vac 60 Hz)
250 Vdc (140 Vac 60 Hz)
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type DPP
Polypropylene Radial Leaded Film Capacitors
Notice and Disclaimer:
All product drawings, descriptions, specifcations, statements, information and
data (collectively, the “Information”) in this datasheet or other publication are subject to change. The
customer is responsible for checking, confrming and verifying the extent to which the Information con-
tained in this datasheet or other publication is applicable to an order at the time the order is placed. All
Information given herein is believed to be accurate and reliable, but it is presented without any guaran-
tee, warranty, representation or responsibility of any kind, expressed or implied. Statements of suitability
for certain applications are based on the knowledge that the Cornell Dubilier company providing such
statements (“Cornell Dubilier”) has of operating conditions that such Cornell Dubilier company regards
as typical for such applications, but are not intended to constitute any guarantee, warranty or representa-
tion regarding any such matter – and Cornell Dubilier specifcally and expressly disclaims any guarantee,
warranty or representation concerning the suitability for a specifc customer application, use, storage,
transportation, or operating environment. The Information is intended for use only by customers who
have the requisite experience and capability to determine the correct products for their application. Any
technical advice inferred from this Information or otherwise provided by Cornell Dubilier with reference
to the use of any Cornell Dubilier products is given gratis (unless otherwise specifed by Cornell Dubilier),
and Cornell Dubilier assumes no obligation or liability for the advice given or results obtained. Although
Cornell Dubilier strives to apply the most stringent quality and safety standards regarding the design
and manufacturing of its products, in light of the current state of the art, isolated component failures may
still occur. Accordingly, customer applications which require a high degree of reliability or safety should
employ suitable designs or other safeguards (such as installation of protective circuitry or redundancies
or other appropriate protective measures) in order to ensure that the failure of an electrical component
does not result in a risk of personal injury or property damage. Although all product-related warnings,
cautions and notes must be observed, the customer should not assume that all safety measures are indi-
cated in such warnings, cautions and notes, or that other safety measures may not be required.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
