Wire Guard |
Spacing 3.5 mm
AK550/..DS-3.5-V-GREY
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.08 mm²
1.5 mm²
0.08 mm²
1.0 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 3.5 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Width (mm)
7.00
10.50
14.00
17.50
21.00
24.50
28.00
31.50
35.00
38.50
42.00
45.50
49.00
52.50
56.00
Article Designation
AK550/2DS-3.5-V-GREY
AK550/3DS-3.5-V-GREY
AK550/4DS-3.5-V-GREY
AK550/5DS-3.5-V-GREY
AK550/6DS-3.5-V-GREY
AK550/7DS-3.5-V-GREY
AK550/8DS-3.5-V-GREY
AK550/9DS-3.5-V-GREY
AK550/10DS-3.5-V-GREY
AK550/11DS-3.5-V-GREY
AK550/12DS-3.5-V-GREY
AK550/13DS-3.5-V-GREY
AK550/14DS-3.5-V-GREY
AK550/15DS-3.5-V-GREY
AK550/16DS-3.5-V-GREY
Article Number
50550020121G
50550030121G
50550040121G
50550050121G
50550060121G
50550070121G
50550080121E
50550090121E
50550100121D
50550110121D
50550120121D
50550130121D
50550140121D
50550150121D
50550160121D
PU
250
250
250
250
250
250
100
100
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 0.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Clamp
Wire Guard
Screw
Brass
Stainless Steel
Steel
5.5 mm
1.2 mm
Accessories
Colours
RAL7016
RAL7032
Figure
GREY , RAL7016
PEBBLE GREY, RAL7032
GREEN, RAL6018
LIGHT GREEN, similar RAL 6018
Designation
Bridge, 2-pole, insulated, BRI/2-7.0/7.62-
L7.5-LIGHT GREY
Article Number
50000000018
RAL6018
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Bridge, 2-pole, BR/2-5.0/5.08-L7.5
50000000015
Bridge, 3-pole, BR/3-3.5/3.81-L7.5
50000000016
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
B
125 V
6A
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.25 kV
C
-
-
-
-
-
-
-
D
-
-
-
-
-
-
-
min
0.5 mm²
0.5 mm²
130 V
13.5 A
max
1.0 mm²
1.0 mm²
0.20 Nm
M2
1.25 kV
www.ptr.eu
