Part Number

Search

D439-R1LL-G2

Description
Basic / Snap Action Switches SPDT QC StrghtLvr 5A 125-250V
CategoryTopical application    Mechanical and electrical/engineering/automation
File Size287KB,2 Pages
ManufacturerCHERRY
Websitehttp://www.cherry-semi.com
Download Datasheet Parametric View All

D439-R1LL-G2 Online Shopping

Suppliers Part Number Price MOQ In stock
D439-R1LL-G2 - - View Buy Now

D439-R1LL-G2 Overview

Basic / Snap Action Switches SPDT QC StrghtLvr 5A 125-250V

D439-R1LL-G2 Parametric

Parameter NameAttribute value
Product CategoryBasic / Snap Action Switches
ManufacturerCHERRY
RoHSDetails
Operating Force285 gf
IlluminatedNon-Illuminated
Factory Pack Quantity160
Miniature Snap Switch
Single and Double Pole
D4 Series
Features
Choice of standard or light operating force
Long life coil spring mechanism
RoHS compliant
Cadmium free
1
Various aux actuators
Various terminal types
Agency approved extended life versions available
Standard Parts
D413-R1AA-G2
D413-R1LA-G2
D413-R1LD-G2
D413-R1RA-G2
D419-R1AA-G2
D423-R1RA-G2
D423-R1RD-G2
1
D429-R1TD-G2
D429-R1AA-G2
D429-R1LD-G2
D429-R1LL-G2
D429-R1MD-G2
D429-R1ML-G2
D433-R1AA-G2
D433-R1LD-G2
D433-R1RA-G2
D433-R1RD-G2
D439-R1LL-G2
D439-V1ML-G2
D443-R1AA-G2
D443-R1LD-G2
D443-R1MD-G2
D443-R1RA-G2
D443-R1RD-G2
D449-R1AA-G2
D449-R1LD-G2
D449-R1LL-G2
D449-R1MD-G2
D449-R1ML-G2
D449-R1RA-G2
D449-R1RD-G2
D453-B8AA-G2
D453-R1AA-G2
D453-R1RA-G2
D453-R1RD-G2
D459-R1AA-G2
D459-R1LD-G2
D459-R1LL-G2
D459-R1ML-G2
The part number configuration matrix below provides details to the part numbers above.
For configurable part numbers that are not listed above, not listed in your region, or for custom part numbers, contact the factory or your distributor.
For information on crossing discontinued U.S. only part numbers, see D4 cross-reference chart at www.cherryswitches.com.
Part Number Breakdown
Series
D4
Contact Rating
2
1
0.1 A
2
3A
3
5A
4
10 A
5
15 A
8
21 A
D413-R1AA-G2
(most part numbers end in –G2; see D4 cross-reference chart for exceptions)
Configuration
3
85
O
C
125
O
C
Standard
Op.
Force
150
O
C
1
2
3
7
8
9
SPST – NO
SPST – NC
SPDT
SPST – NO
SPST – NC
SPDT
Light Op.
Force
G
H
M
N
P
R
SPST – NO
SPST – NC
SPDT
SPST – NO
SPST – NC
SPDT
S
T
U
SPST – NO
SPST – NC
SPDT
Light
Op.
Force
2
3
UL AC current rating; see table on reverse for complete details
D48 only available with light operating force
Q3
R1
R3
S1
V1
V3
W9
Y5
Z5
Terminal Type mm (inches)
4.8 x 0.8 (0.187 x 0.032) QC, dog leg*
4.8 x 0.5 (0.187 x 0.020) QC, straight**
4.8 x 0.5 (0.187 x 0.020) QC, dog leg**
Solder with temp stop
6.3 x 0.8 (0.250 x 0.032) QC, straight
6.3 x 0.8 (0.250 x 0.032) QC, dog leg
Screw*
6.3 x 0.8 (0.250 x 0.032) QC, 5 mm grid
6.3 x 0.8 (0.250 x 0.032) QC, 7 mm grid
Actuator Type mm (inches)
Actuation length
Actuation length
AA Button
N/A
MA
25.7 (1.01)
JA SS lever, standard ratio 21.2 (0.835)
ML
74.4 (2.93)
JD SS lever, standard ratio 35.6 (1.4)
RA
20.6 (0.811)
JL
SS lever, standard ratio 69.9 (2.75)
RD
34.1 (1.34)
KA SS lever, high ratio
25.7 (1.01)
SA
20.6 (0.811)
KL SS lever, high ratio
74.4 (2.93)
TA
25.1 (0.988)
LA Lever, standard ratio
21.2 (0.835)
TD
38.6 (1.52)
LD Lever, standard ratio
35.6 (1.4)
UA
25.1 (0.988)
LL
Lever, standard ratio
69.9 (2.75)
For actuator details, see D4 actuator reference sheet at www.cherryswitches.com
A1
Welding
B8
Short solder
C1
2.8 x 0.8 (0.110
C3
2.8 x 0.8 (0.110
P4
1.2 x 0.5 (0.047
P5
1.2 x 0.5 (0.047
PA
1.2 x 0.5 (0.047
PB
1.2 x 0.5 (0.047
Q1
4.8 x 0.8 (0.187
*not available for D48
x 0.032) QC, bifurcated straight**
x 0.032) QC, bifurcated dog leg**
x 0.020) PCB, underside*
x 0.020) PCB, rear*
x 0.020) PCB, housing side*
x 0.020) PCB, cover side*
x 0.032) QC, straight*
**not available for D45 or D48
www.cherryswitches.com
Page 1 of 2, Last saved by 2015-02-26, Specifications subject to change without notice.
