C4 SERIES INPUT MODULES
• Plug into mounting boards for C4 Series modules
• AC Inputs (Yellow Case)
• DC Inputs (White Case)
• 4kV Optical isolation
• Open-collector Output
• Industry standard packaging
• Built-in LED Status Indicator
SPECIFICATIONS (1)
Input
Part Number
Voltage Range
Maximum Current [mA](2)
Resistance [Ohms](3)(4)
Drop-out Current [mA](5)
Allowable Voltage for No Output [VAC/VDC](6)
Allowable Current for No Output [mA](6)
C4IAC
90-140 VAC
14
22 k
3
50
2.5
C4IACA
180-280 VAC
5
75 k
1
50
0.7
C4IDC
10-32 VDC
20
2k
1.5
3.0
1.0
Output
Maximum Logic Supply Voltage[VDC]
Maximum Output Voltage Drop [VDC](7)
Minimum Logic Supply Voltage [VDC]
Logic Supply Voltage Range [VDC]
Maximum Current [mA](8)
Maximum Logic Supply Current [mA](9)
Maximum Logic Supply Leakage Current [µA]10)
Maximum Supply Idle Current [µA](11)
Maximum Turn-On Time [msec] (12)
Maximum Turn-Off Time [msec] (12)
30
0.2
4.5
4.5-30
50
25.0
10.0
10.0
20
20
30
0.2
4.5
4.5-30
50
25.0
10.0
10.0
20
20
30
0.2
4.5
4.5-30
50
25.0
10.0
10.0
5.0
5.0
SPECIFICATIONS (1)
Input
Part Number
Voltage Range
Maximum Current [mA](2)
Resistance [Ohms](3)(4)
Drop-out Current [mA](5)
Allowable Voltage for No Output [VAC/VDC](6)
Allowable Current for No Output [mA](6)
C4IDCB
4-16 VDC
40
400
2
1
0.7
C4IDCG
35-60 VDC
10
10 k
1
7
0.7
C4IDCK
2.5-16 VDC
60
300
2
1
0.2
Output
Maximum Logic Supply Voltage[VDC]
Maximum Output Voltage Drop [VDC](7)
Minimum Logic Supply Voltage [VDC]
Logic Supply Voltage Range [VDC]
Maximum Current [mA](8)
Maximum Logic Supply Current [mA](9)
Maximum Logic Supply Leakage Current [µA]10)
Maximum Supply Idle Current [µA](11)
Maximum Turn-On Time [msec] (12)
Maximum Turn-Off Time [msec] (12)
30
0.2
4.5
4.5-30
50
25.0
10.0
10.0
0.05
0.1
30
0.2
4.5
4.5-30
50
25.0
10.0
10.0
10.0
10.0
30
0.2
4.5
4.5-30
50
25.0
10.0
10.0
0.025
0.025
GENERAL SPECIFICATIONS
Description
Input/Output Isolation Voltage (13)
Input/Output Capacitance
Operating Temperature Range
Storage Temperature Range
Weight
Parameters
4000 VAC
8 pF
-30 to 80°C
-40 to 100°C
1.1 oz. (31.2g)
GENERAL NOTES:
(1)
(2)
(3)
(4)
(5)
Specifications apply to an ambient temperature of -30 to 80 °C unless otherwise noted.
Measured at maximum specified input voltage, 25°C.
Resistance values for C4IAC modules are effective impedance values at 25 °C.
Resistance values are +/-10% at 25 °C.
Defined as the maximum current allowed through the module's input to guarantee that
the output will switch from "on" to "off". Higher currents may result in the output remaining
in the "on" state.
Defined as the maximum voltage/current allowed through the module's input that will not
switch the module's output state from "off: to "on".
At maximum output current and 25°C
Maximum allowable sinking current through open collector output transistor
At maximum logic supply voltage and 25°C.
At maximum output voltage and 25°C.
At maximum specified logic voltage and 25°C.
At 15 VDC logic, 30 VDC output, 50 mA, 25°Cand nominal input voltage.
At 25°C for 1 second maximum duration.
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
MECHANICAL SPECIFICATIONS
AGENCY APPROVALS
E46203
38595
Rev. 121311
