440LS10MMAJ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> 440LS10MMAJ

440LS10MMAJ: DescriptionCeramic Disc Capacitors .01uF X7R 10% X1, 400Vac/Y1,500Vac; CategoryPassive components; File Size176KB，5 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

440LS10MMAJ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	440LS10MMAJ	-	-	View	Buy Now

440LS10MMAJ Overview

Ceramic Disc Capacitors .01uF X7R 10% X1, 400Vac/Y1,500Vac

440LS10MMAJ Parametric

Parameter Name	Attribute value
Product Category	Ceramic Disc Capacitors
Manufacturer	Vishay
RoHS	No
Capacitance	0.01 uF
Voltage Rating AC	500 VAC/760 VAC
Dielectric	Y5U
Tolerance	20 %
Diameter	21.6 mm
Lead Spacing	9.5 mm
Minimum Operating Temperature	- 30 C
Maximum Operating Temperature	+ 125 C
Termination Style	Radial
Product	Safety Ceramic Disc Capacitors
Application	Safety
Capacitance - nF	10 nF
Capacitance - pF	10000 pF
Class	X1, Y1
Dissipation Factor DF	2
Operating Temperature Range	- 30 C to + 125 C
Factory Pack Quantitydvvcfbcecrtbcdfasruzwfrcyfedrwq	100
Temperature Coefficient	- 56 %, + 22 %
Temperature Coefficient / Code	Y5U
Type	AC Line Rated Ceramic Disc Capacitors Class X1 760 VAC/Y1 500 VAC
Voltage Rating	400 VAC

Preview

Download Datasheet

View All

440L Series

www.vishay.com

Vishay Cera-Mite

AC Line Rated Ceramic Disc Capacitors

Class X1, 760 V

/ Class Y1, 500 V

FEATURES

• Complies with IEC 60384-14, 4

edition

• High reliability

• Radial leads

• High capacitance up to 20 nF

• Singlelayer AC disc safety capacitors

• Material categorization: for definitions of compliance

please see

www.vishay.com/doc?99912

APPLICATIONS

• X1, Y1 according to IEC 60384-14.4

• Across-the-line

DESIGN SUPPORT TOOLS

Models

Available

click logo to get started

• Line by-pass

• Antenna coupling

DESIGN

The capacitors consist of a ceramic disc of which both sides

are silver-plated. Connection leads are made of tinned

copper having a diameter of 0.032" (0.81 mm). The

capacitors may be supplied with radial kinked or straight

leads having a lead spacing of 0.375" (9.5 mm). The

standard tolerances are ± 10 % or ± 20 %. Coating is made

of flame-retardant epoxy resin in accordance with

“UL 94 V-0.”

QUICK REFERENCE DATA

DESCRIPTION

Ceramic Class

Ceramic Dielectric

Voltage (V

)

Min. Capacitance (pF)

Max. Capacitance (pF)

Mounting

C0G,

U2J,

P3K,

R3L

500

Radial

C0G,

U2J,

P3K,

R3L

760

X7R,

Y5U

500

20 000

VALUE

X7R,

Y5U

760

CAPACITANCE RANGE

10 pF to 20 nF

RATED VOLTAGE

INSULATION RESISTANCE

Min. 1000

F

IEC 60384-14.4:

• X1:

• Y1:

760 V

, 50 Hz

500 V

, 50 Hz

TOLERANCE ON CAPACITANCE

± 10 %; ± 20 %

DIELECTRIC STRENGTH BETWEEN LEADS

Component test:

4000 V

, 50 Hz, 2 s

As repeated test admissible only once with:

3600 V

, 50 Hz, 2 s

Random sampling test (destructive test):

4000 V

, 50 Hz, 60 s

DISSIPATION FACTOR

2.0 % max. at 1 kHz; 1 V

CERAMIC DIELECTRIC

C0G, U2J, P3K, R3L (class 1)

X7R, Y5U (class 2)

OPERATING TEMPERATURE RANGE

-30 °C to +125 °C

DIELECTRIC STRENGTH OF BODY

INSULATION

4000 V

, 50 Hz, 60 s (destructive test)

CLIMATIC CATEGORY ACC. TO EN 60068-1

25/125/21

Revision: 29-Mar-18

Document Number: 23102
