FEATURES
APPLICATIONS
Small Size
-
High Ripple Current
–
Super Low ESR
DC-DC Converters
–
Voltage Regulators
–
Motherboards
–
De-Coupling
Operating Temperature Range
Capacitance Tolerance
WVDC
Surge Voltage
SVDC
WVDC
Dissipation Factor
Tan δ
-55°C to +105°C
+20% at 120 Hz, 20°C
20
25
35
1.15*WVDC
16
20
25
35
.12 MAX @120 Hz, 20°C
2 Minutes
0.2CV or 280uA,
Whichever is greater
<1.25
<1.25
2000 hours at 105°C with rated WVDC and ripple current applied
Capacitance Change
<20% of initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
1000 cycles at 20°C with rated surge voltage applied for 30 seconds through a 1kΩ
resistor and discharged for 5 minutes and 30 seconds
Capacitance Change
<20% initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
1000 hours at 60°C and 90 to 95% RH with no voltage applied
Capacitance Change
<20% initial measured value
Dissipation Factor
<150% of maximum specified value
ESR
<150% of maximum specified value
Leakage Current
<100% of maximum specified value
Frequency (Hz)
120 Hz<f<1kHz
1 kHz<f<10 kHz
10 kHz<f<100kHz
100 kHz<f<500kHz
0.05
0.3
0.7
1.0
16
Leakage Current
Low Temperature
Stability
Impedance Ratio
(100 kHz)
-55°C/ +20°C
+105°C/ +20°C
Load Life
Surge Voltage Life
Damp Heat Test
Ripple Current Multipliers
DxL
6.3x8
S
2.5
d
0.6
L
1
=L+1.0 mm Max.
L
1
=L+1.5 mm Max.
D
1
=D+0.5mm Max.
S
1
=S+0.5 mm
8x8
8x11.5
3.5
3.5
0.6
0.6
(D<8mm)
(D>8mm)
10x12.5
3.0
0.6
mm
Feb-17
