T93
www.vishay.com
Vishay Sfernice
3/8" Square Multi-Turn Cermet Trimmer
FEATURES
• Industrial grade
• 0.5 W at 70 °C
• Tests according to CECC 41000 or IEC 60393-1
DESIGN SUPPORT TOOLS
Models
Available
click logo to get started
• Contact resistance variation < 2 %
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
The T93 is a small size trimmer - 3/8" x 3/8" x 3/16" - answering PC board mounting requirements. Five versions are available
which differ by the position of the control screw in relation to the PC board plane and by the spacing of the terminals. Excellent
operational stability is provided by the use of a cermet element.
DIMENSIONS
in millimeters (± 0.5 mm)
T93XA
2.3 ± 0.2
(1)
9.8 max. 5 ± 1
5 max
a
b
c
Terminal Spacing on
a 2.54 PCB
2.54
2.54
ø 0.5
9.7 max
1.3
0.5
1.2 ± 0.2
7.9 ± 0.2
a
b
c
Slot 0.6 x 0.6
ø 2.2
T93XB
2.54
0.6 ± 0.2
(1)
9.8 max
5±1
5 max
2.54
(1)
2.54
(1)
a
b
c
1.3
0.5
ø 0.5
9.7 max
a
b
c
ø 2.2
Slot 0.6 x 0.6
1.2 ± 0.2
7.9 ± 0.2
1.2 ± 0.1
1.6 ± 0.1
ø 2.2
T93YA
2.3 ± 0.2
(1)
1.3
9.8 max
5±1
2.54
(1)
2.54
(1)
a
b
c
0.5
9.7 max
ø 0.5
5 max
a
b
c
slot 0.6 x 0.6
T93YB
0.6 ± 0.2
(1)
2.54
1.3
ø 2.2
9.8 max
5±1
1.2 ± 0.1
1.6 ± 0.1
9.7 max
ø 0.5
2.54
(1)
2.54
(1)
a
b
c
slot 0.6 x 0.6
0.5
5 max
5.2 max
5±1
2.54
(1)
a
b
c
T93Z
Slot 0.6 x 0.6
4.8 ± 0.2
(1)
9.7 max
2.54
(1)
2.54
(1)
ø 2.2
1.3
9.7 max.
c
b
a
ø 0.5
Base level
c
b
a
1.3 ± 0.1
1.2 ± 0.1
0.5
Note
(1)
To be measured at base level
Revision: 26-Jan-18
Document Number: 51026
1
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T93
www.vishay.com
Vishay Sfernice
Cermet
21 turns ± 2
10
to 2.2 M
1 - 2.2 - 4.7 and on request 1 - 2 - 5
Standard
10 %
5%
0.5 W at +70 °C
ELECTRICAL SPECIFICATIONS
Resistive element
Electrical travel
Resistance range
Standard series E3
Tolerance
On request
linear
0.5
POWER IN W
Power rating
0
0
25
50
70
100
125
155
AMBIENT TEMPERATURE IN °C
a
c
(3)
b
(2)
cw
Circuit diagram
(1)
Temperature coefficient
Limiting element voltage (linear law)
Contact resistance variation
End resistance (typical)
Dielectric strength (RMS)
Insulation resistance (500 V
DC
)
See Standard Resistance Element table
250 V
2 % Rn or 2
1
1000 V
10
6
M
MECHANICAL SPECIFICATIONS
Mechanical travel
Operating torque (max. Ncm)
End stop torque
Net weight
Wiper (actual travel)
Terminals
23 turns ± 5
1.5
Clutch action
Approx. 0.82 g
Positioned at approx. 50 %
Pure Sn (code e3)
ENVIRONMENTAL SPECIFICATIONS
Temperature range
Climatic category
Sealing
-55 °C to +125 °C
55/125/56
Fully sealed - IP67
Revision: 26-Jan-18
Document Number: 51026
2
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T93
www.vishay.com
Vishay Sfernice
LINEAR LAW
MAX. POWER
AT 70 °C
W
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.28
0.13
0.06
0.028
MAX. WORKING
VOLTAGE
V
2.2
3.3
4.8
7
10.5
15.3
22.4
33.2
48.5
70.7
105
153
224
250
250
250
250
MAX. CURRENT
THROUGH WIPER
mA
224
150
103
70
47
32
22
15
10
7
4.8
3.2
2.2
1.1
0.53
0.25
0.11
TYPICAL
TCR
-55 °C
+125 °C
ppm/°C
STANDARD RESISTANCE ELEMENT DATA
STANDARD
RESISTANCE
VALUES
10
22
47
100
220
470
1K
2.2K
4.7K
10K
22K
47K
100K
220K
470K
1M
2.2M
± 100
PERFORMANCES
TESTS
Load life
CONDITIONS
1000 h at rated power
90'/30' - ambient temp. 70 °C
Phase A dry heat 125 °C - 30 % Pr
Phase B damp heat
Phase C cold -55 °C
Phase D damp heat 5 cycles
56 days
40 °C, 93 % RH
5 cycles
-55 °C to +125 °C
50 g at 11 ms
3 successive shocks
in 3 directions
10 Hz to 55 Hz
0.75 mm or 10 g
during 6 h
200 cycles
TYPICAL VALUES AND DRIFTS
R
T
/R
T
(%)
±1%
Contact res. variation: < 1 % Rn
± 0.5 %
± 0.5 %
Dielectric strength: 1000 V
RMS
Insulation resistance: > 10
4
M
± 0.5 %
± 0.1 %
R
1-2
/R
1-2
(%)
±2%
Climatic sequence
±1%
Long term damp heat
Rapid temperature change
Shock
±1%
V
1-2
/V
1-3
± 1 %
± 0.2 %
V
1-2
/V
1-3
± 0.2 %
-
Vibration
Rotational life
± 0.1 %
±4%
Contact res. variation: < 1 % Rn
Note
• Nothing stated herein shall be construed as a guarantee of quality or durability
MARKING
•
•
•
•
•
•
•
Vishay trademark
Model
Style
Ohmic value (in
,
k, M)
Tolerance (in %)
Manufacturing date
Marking of terminal 3
Revision: 26-Jan-18
Document Number: 51026
3
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T93
www.vishay.com
Vishay Sfernice
PACKAGING
• In tube of 50 pieces code T20 (TU50)
ORDERING INFORMATION
(part number)
T
9
3
X
A
2
2
4
K
T
2
0
Model
T93
STYLE
XA
XB
YA
YB
Z
OHMIC VALUE
From
10
to 2.2 M
224
= 220 k
TOLERANCE
K
= 10 %
on request
J
= 5 %
PACKAGING
T20
= tube
50 pieces
SPECIAL
NUMBER
(If applicable)
Given by
Vishay
for custom
design
DESCRIPTION
(for information only)
T93
MODEL
XA
STYLE
220K
VALUE
10 %
TOLERANCE
SPECIAL
TU50
PACKAGING
e3
LEAD FINISH
RELATED DOCUMENTS
APPLICATION NOTES
Potentiometers and Trimmers
Guidelines for Vishay Sfernice Resistive and Inductive Components
www.vishay.com/doc?51001
www.vishay.com/doc?52029
Revision: 26-Jan-18
Document Number: 51026
4
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
