Material
Plating
Wire Size
Wire Type
High Conductivity
Seamless Copper Tube
Electro-Tin
8 STR/FLEX
.48±.04
8 STR/FLEX
LCCX8-14AH
.37 R REF
PANDUIT
Stranded Copper: Class B & C,
Compact, Class G, H, I, K, M,
Locomotive
3/4 in.
1/4 in.
Yes, for applications up to 35kv.
Consult cable manufacturer for
voltage stress relief instructions
with applications greater than
2000 volts.
90 C
Yes
RED
PANDUIT
RED DIE P21
Wire Strip Length
Stud Size
UL Listed Wire
Connector
.25±.04
.63±.02
.27±.02 DIA
(2) PLS
Color coded
barrel markings
UL Temperature
Rating
C.S.A Certified
Wire Connector
Panduit Color Code
on Barrel
Beveled wire entry
.27±.01
.18±.01
.70±.04
Panduit Die Index No. P21
on Barrel
Alternate Industry
Die Index No. ( )
on Barrel
N/A
Wire inspection window
45°±5°
.83 REF
.07±.01
1.91 REF
CERTIFIED
LISTED
Wire Connector
CORP.
00
REV
TINLEY PARK, ILLINOIS
6/03
DATE
SAC SAC
BY
CHK
RELEASED
DESCRIPTION
10850
ECN
LCCX8-14AH-L
Copper Lug - Two-Hole, Long Flex Barrel with Window, 45° Angle Tongue
SCALE
N/A
DRAWING NO / CAD FILE
LCCX8-14AH-CUST
