Types LC
EIA Class 3, Semiconductor Type
Reduced Titanite Disc Ceramic Capacitors
EIA Class 3 reduced titanite disc ceramic capacitors are
ideal for use in transistorized circuity for bypass and
coupling applications.
Highlights
Specifications
Capacitance Range:
Voltage Range:
Tolerance:
Operating Temperature Range:
Insulation Resistance:
Breakdown Voltage:
ltage:
Power
Factor:
Lead Length:
Ratings
Catalog
Cap
(µF)
.010
.100
LC103M*
LC104M*
Part Number
Tol.
l.
(±)
Temp.
LE
Size
C
Coef.
D
T
S
(Inches)
25 Vdc
.235
.495
.138
.138
.250
.250
Y5R**
Y5R**
<
.01 to .10 µF
25 Vdc
±20%
–30 ºC to +85 ºC
1 megohm minimum
2.5 x rated (5 seconds Max.)
1.5% Max. @ 1 KHz
1.0 inch minimum
TE
Size
d
D
T
S
.025
.025
6.0
12.6
3.5
3.5
High Capacitance
Low power factor
Superior radio frequency impedance
Meets RS-198C for Class 3 ceramic capacitors
Radial leads
O
20%
20%
d
(Millimeters)
6.4
6.4
.6
.6
*available only until stock is depleted
deplete
**maximum capacitance change over temperature rating: ±15%
Physical Specifications
Case:
Conformal Coating
Lead material:
Tinned copper wire. (Minimum lead content: 5%)
O
For D less than .315 (8.0mm)
CDE Cornell Dubilier 1605 E. Rodney French Blvd. New Bedford, MA 02744 Phone: (508)996-8561 Fax: (508)996-3830 www.cde.com
BS
Tape and Reel Available upon Request
Leads are formed to .200 (5.0mm) lead spacing
- Quantity/Reel = 2500 pcs
Tape and reel not available for greater than .472” (12mm)
