Type DPPM
Polypropylene Film Capacitors
Foil/Metallized Hybrid, Radial Leaded
Great for Compact Snubber Applications
Type DPPM
radial-leaded, film/foil polypropylene
capacitors utilize series wound extended foil with floating
metallized common film construction.
Type DPPM
offers
excellent high frequency and high current capabilities
and self-healing characteristics. With low inductance and
high dV/dt characteristics,
Type DPPM
is ideal for snubber
applications.
Specifications
Capacitance Range:
.001-.047 µF
Voltage Range:
1000-2000 Vdc (450-500 Vac, 60 Hz)
Capacitance Tolerance:
±10% (K) standard
Operating Temperature Range:
-40 °C to 105 °C*
Dielectric Strength:
175% (1 minute)
Dissipation Factor:
0.1%
Max. (25 °C, 1kHz)
Insulation Resistance:
400,000 M
Ω
Min.
Life Test:
500 hours at 85 °C at 125% rated voltage
L
MAX.
MAX.
T
±5% (J), ±20% (M) optional
.984 MIN.
(25mm)
H MAX.
*Full-rated voltage at 85 °C–Derate linearly to 50%-rated voltage at 105 °C
1.5mm
MAX.
d
TINNED
COPPER
S
±.06 (±1.5)
NOTE:
Other capacitance values, sizes and performance
pecifications are available. Contact us.
Ratings
Cap.
µF
Catalog
Part Number
T
Inches (mm)
H
L
Inches (mm)
Inches
1000 Vdc (450 Vac)
0.452 (11.5)
0.984
0.452 (11.5)
0.984
0.452 (11.5)
0.984
0.452 (11.5)
0.984
0.452 (11.5)
0.984
0.472 (12.0)
0.984
S
(mm)
Inches (mm)
RoHS Compliant
d
Inches
(mm)
dV/dt
V/μs
.0010
.0012
.0015
.0018
.0022
.0027
.0033
.0039
.0047
.0056
.0068
.0082
.010
.012
.015
.018
.022
.027
.033
.039
.047
DPPM10D1K-F
DPPM10D12K-F
DPPM10D15K-F
DPPM10D18K-F
DPPM10D22K-F
DPPM10D27K-F
DPPM10D33K-F
DPPM10D39K-F
DPPM10D47K-F
DPPM10D56K-F
DPPM10D68K-F
DPPM10D82K-F
DPPM10S1K-F
DPPM10S12K-F
DPPM10S15K-F
DPPM10S18K-F
DPPM10S22K-F
DPPM10S27K-F
DPPM10S33K-F
DPPM10S39K-F
DPPM10S47K-F
0.256
0.256
0.256
0.256
0.256
0.275
0.275
0.275
0.295
0.314
0.334
0.334
0.374
0.393
0.374
0.393
0.433
0.472
0.511
0.551
0.590
(6.5)
(6.5)
(6.5)
(6.5)
(6.5)
(7.0)
(7.0)
(7.0)
(7.5)
(8.0)
(8.5)
(8.5)
(9.5)
(10.0)
(9.5)
(10.0)
(11.0)
(12.0)
(13.0)
(14.0)
(15.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(25.0)
(31.0)
(31.0)
(31.0)
(31.0)
(31.0)
(31.0)
(31.0)
0.826
0.826
0.826
0.826
0.826
0.826
0.826
0.826
0.826
0.826
0.826
0.826
0.826
0.826
1.043
1.043
1.043
1.043
1.043
1.043
1.043
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(21.0)
(26.5)
(26.5)
(26.5)
(26.5)
(26.5)
(26.5)
(26.5)
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
0.032
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
(0.8)
1900
1900
1900
1900
1900
1900
1900
1900
1900
1900
1900
1900
1900
1900
1300
1300
1300
1300
1300
1300
1300
0.492
0.511
0.531
0.551
0.570
0.629
0.649
0.688
0.669
0.688
0.728
0.767
0.807
0.846
0.885
(12.5)
(13.0)
(13.5)
(14.0)
(14.5)
(16.0)
(16.5)
(17.5)
(17.0)
(17.5)
(18.5)
(19.5)
(20.5)
(21.5)
(22.5)
0.984
0.984
0.984
0.984
0.984
0.984
0.984
0.984
1.220
1.220
1.220
1.220
1.220
1.220
1.220
