DataSheet
SeriesOne DR Series
AC
DC
DIN Rail Mount
•
Ratings of 6 & 12 Amps
•
Load voltage ratings of 1-60 VDC, 1-100 VDC, 24-280 VAC and 48-600 VAC
•
Fits standard 35mm DIN Rail
•
LED input status indicator
•
AC or DC control
•
Zero Voltage (resistive loads) or Instantaneous (inductive loads) turn-on output
•
UL and cUL Listed, HP Rated CE & RoHS Compliant
•
UL 508 Endurance Rating for Enhanced Reliability
•
UL Class I and II, Division 2, for Hazardous Locations
PRODUCT SELECTION
Control Voltage
4-32 VDC
90-140 VAC
200-280 VAC
18-36 VAC
280, 6 A
DR24D06
DR24B06
DR24A06
DR24E06
280V, 12 A
DR24D12
DR24B12
DR24A12
DR24E12
600V, 6 A
DR48D06
600V, 12 A
DR48D12
DR48B12
DR48A12
DR48E12
60V, 6 A
DR06D06
60V, 12 A
DR06D12
100V, 6 A
DR10D06
100V, 12 A
DR10D12
AVAILABLE OPTIONS
Operating Voltage
06:
1-60 VDC
10:
1-100 VDC
24:
24-280 VAC
48:
48-600 VAC
Rated Load Current
06:
6 Amps
12:
12 Amps
Switching Type
Blank:
Zero Voltage Turn-On
(AC Output Only)
R:
Instantaneous Turn-On
(AC Output, D suffix Only)
Series
DR
06
D
12
X
R
Agency Approvals
Control Voltage
X:
ATEX II 3G Ex nA IIC T4 Gc
D:
4-32 VDC
approved
A:
200-265 VAC
AC
Output
B:
90-140 VAC
E:
18-36 VAC
(1)
Only
Required for valid part number
For options only and not required for valid part number
OUTPUT SPECIFICATIONS AC Output
(2)
Description
Operating Voltage Range (47-63Hz) [Vrms]
Transient Overvoltage [Vpk]
Maximum Load Current, resistive [Arms]
(3)
Minimum Load Current [mArms]
Maximum Off-State Leakage Current @ Rated Voltage [mArms]
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/
µ
sec]
(4)
Maximum On-State Voltage Drop @ Rated Current [Vrms]
Maximum Surge Current (50/60Hz, 1 cycle) [Apk]
Maximum I²t for Fusing (50/60 Hz, 1/2 cycle) [A² sec]
HP Rating UL 508/IEC60947 [HP (KW)] @ 240V
HP Rating UL 508/IEC60947 [HP (KW)] @ 380V
HP Rating UL 508/IEC60947 [HP (KW)] @ 480V
Minimum Power Factor (at Maximum Load)
Min/Max stranded wire
Min/Max solid wire
Weight (Typical)
DR24x06
24-280
600
6
150
0.1
500
1.3
285/300
400/375
1/2 (.37)
1 (.75)
N/A
0.5
22/14 AWG
22/14 AWG
1.76 oz. (50g)
DR24x12
24-280
600
12
150
0.1
500
1.3
715/750
2560/2330
1 (.75)
2 (1.5)
3 (2.2)
0.5
22/14 AWG
22/14 AWG
3.17 oz. (90g)
DR48x06
48-600
1200
6
150
0.1
500
1.3
285/300
410/375
1/2 (.37)
1 (1.5)
2 (1.5)
0.5
22/14 AWG
22/14 AWG
1.76 oz. (50g)
DR48X12
48-600
1200
12
150
0.1
500
1.3
715/750
2560/2330
1 (.75)
2 (1.5)
3 (2.2)
0.5
22/14 AWG
22/14 AWG
3.17 oz. (90g)
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
DataSheet
OUTPUT SPECIFICATIONS DC Output
(2)
Description
Operating Voltage [VDC]
Maximum Load Current [Adc]
(3)
Minimum Load Current [mAdc]
Maximum Off-State Leakage Current @ Rated Voltage [mA]
Maximum On-State Voltage Drop @ Rated Current [Vpk]
Maximum Surge Current (10ms) [Apk]
On-State resistance at rated current [Ohms]
Min/Max stranded wire
Min/Max solid wire
Weight (typical)
DIN Rail Mount
DR06D12
1-60
12
2.5
0.1
0.6
100
0.45
22/14 AWG
22/14 AWG
3.17 oz (90g)
DR06D06
1-60
6
2.5
0.1
0.6
60
0.1
22/14 AWG
22/14 AWG
1.94 oz. (55g)
DR10D06
1-100
6
2.5
0.1
0.6
60
0.1
22/14 AWG
22/14 AWG
1.76 oz. (50g)
DR10D12
1-100
12
2.5
0.1
0.6
100
0.45
22/14 AWG
22/14 AWG
3.17 oz.(90g)
INPUT SPECIFICATIONS
(2)
Description
Control Voltage Range
(5)
Minimum Turn-On Voltage
Must Turn-Off Voltage
Minimum Input Current for [mA]
(6)
Maximum Input Current for [mA]
(6)
Maximum Turn-on Time [msec]
(7) (8)
Maximum Turn-off Time [msec]
(9)
Min/Max stranded/solid wire
DRxxDxx
4-32 VDC
4.0 VDC
1.0 VDC
9
11
1/2 Cycle
1/2 Cycle
22/16 AWG
DRxxBxx
90-140 Vrms
90 Vrms
10 Vrms
3
5
20 msec
30 msec
22/16 AWG
DRxxAxx
200-265 Vrms
200 Vrms
40 Vrms
2.5
3.3
20 msec
30 msec
22/16 AWG
DRxxExx
18-36 Vrms
(1)
18 Vrms
4 Vrms
3.5
8
20 msec
30 msec
22/16 AWG
GENERAL SPECIFICATIONS
(2)
Description
Dielectric Strength, Input/Output/Base (50/60Hz)
Minimum Insulation Resistance (@ 500 VDC)
Maximum Capacitance, Input/Output
Ambient Operating Temperature Range
Ambient Storage Temperature Range
Recommended Terminal Screw Torque Range
Parameters
4000 Vrms
(10)
10
9
Ohm
10 pF
-30 to 80 °C
-30 to 100 °C
4.4-7.0 in-lb (0.5-0.8Nm)
GENERAL NOTES
(1)
E option is UL certified for AC control voltage, but it works also with 18-36 VDC input range.
(2)
All parameters at 25°C unless otherwise specified.
(3)
See Derating curves
(4)
Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
(5)
DC control includes reverse polarity protection.
(6)
Input circuitry incorporates active current limiter.
(7)
Turn-on time for DC control random turn-on versions is 0.1 msec.
(8)
Turn-on time for DC output 600
µsec
.
(9)
Turn-off time for DC output 300
µsec
.
(10)
2500Vrms for DC output.
Standards of Compliance
IEC 62314
LC A, Resistive or Slightly Inductive Load Ratings: 12 A @40°C ambient for DR24x12, 12 A @ 40°C ambient for DR48x12
LC A, Resistive or Slightly Inductive Load Ratings: 6 A @ 40°C ambient for DR24x06, 6 A @ 40°C ambient for DR48x06
LC B, Motor Loads Ratings: 0.75KW @ 240 VAC for DR24x06 and 2.2KW @ 480 VAC DR48x12
LC B, Motor Loads Ratings: 0.375KW @ 240 VAC for DR24x06 and 1.5KW @ 480 VAC DR48x12
Shock and Vibration
(Applies to all part numbers)
Vibration Resistence according to IEC 60068-2-6:
0.35mm and 0.75mm Amplitude over 10-55 Hz
Shock Resistance according to IEC 60068-2-27:
15g/11ms
EMC
(Applies to all part numbers)
IEC 61000-4-2: Electrostatic Discharge- Level 3
IEC 61000-4-4: Electrically Fast Transients- Level 3
IEC 61000-4-5: Electrical Surges- Level 3
ANSI / ISA 12.12.01-2013
Nonincendive Electrical Equipment for Use in Class I and II, Division 2 and Class III, Division 1 and 2 Hazadous (classified) locations
This equipment is open-type device and is meant to be installed in an enclosure suitable for the enviroment such that the equipment is only accesible with the use of a tool
suitable for use in Class 1, Division 2, Group A,B,C and Hazardous locations, or Nonhazardous locations only
WARNING-Explosion Hazard- Do not disconnect equipment while the circuit is live or unless the area is known to be free of ignitable concentrations
WARNING-Explosion Hazard- Substitution of any component may impair suitability for Class I, Division 2
Do not forget to visit us at:
www.crydom.com
Copyright © 2017 Crydom Inc. Specifications subject to change without notice.
