SC648AH datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Topical application> Mechanical and electrical/engineering/automation> SC648AH

SC648AH: DescriptionAudio Indicators u0026 Alerts MED CONT 10-48V; CategoryTopical application Mechanical and electrical/engineering/automation; File Size78KB，1 Pages; ManufacturerMallory; Websitehttps://www.msdperformance.com/brands/mallory/

Download Datasheet Parametric View All

SC648AH Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SC648AH	-	-	View	Buy Now

SC648AH Overview

Audio Indicators u0026 Alerts MED CONT 10-48V

SC648AH Parametric

Parameter Name	Attribute value
Product Category	Audio Indicators & Alerts
Manufacturer	Mallory
RoHS	No RoHS Version Available
Sound Pressure Level	80 dBA
Tone	Siren
Voltage Rating	48 VAC/DC
Current Rating	16 mA
Termination Style	Screw
Mounting	Panel
Features	Pin Terminal Available
Length	1.68 mm
Length - in	0.066 in
Length - mm	1.68 mm
Factory Pack Quantity	1
Type	Transducers

Preview

Download Datasheet

View All

Mallory Sonalert Products, Inc.

Revision:

Sales Outline Drawing

Specifications:

Sound Level Category

Mode of Operation

Voltage Rating

Frequency

Loudness @ 2 FT

Loudness @ Min Vdc

Loudness @ Max Vdc

Current Draw

Housing Material

Storage Temperature

Operating Temperature

Panel Mounting

Knurled Nut

Weight (Typical)

NEMA 3R,4X, & 12

Options

Part #:

SC648AH

Medium

Continuous

10 to 48 VAC/DC

4500 ± 500 Hz

80 to 93 dB(A) Typ.

68 dB(A) @ 2 Feet and Vdc

80 dB(A) @ 2 Feet and Vdc

4-16mA

6/6 Nylon, Color: Black

-40° to +85° C

-30° to +65° C

Recommended hole size is 1.25"(31.75mm). Thread front will fit standard 30mm(1.181") hole.

Used to attach part to panel. The max recommended torque is 10 in-lbs.

1.6 oz (45g)

Approved with use of ACC03.

Please contact factory.

PART DIMENSIONS AFTER CODE DATE:

0914 1

Dimensions:

Inches (mm)

PART DIMENSIONS BEFORE CODE DATE:

0913 5

4411 South High School Road, Indianapolis, Indiana 46241 U.S.A · Phone: (317) 612-1000 Fax: (317) 612-1010

www.mallory-sonalert.com
