SMALL-SIZED ROCKER SWITCHES
A high powered offering packed into a small-sized envelope, the 622/632-Series is a staple of numerous
markets. With its silver-alloy butt contacts, the 622/632 will handle inrush spikes up to 100 amps and
steady state current to 12A 125VAC. The lighted 632-Series features a multitude of illumination circuit
options available with LED, incandescent and neon style lamps.
Product Highlights:
Illuminated or Non-Illuminated
Silver Plated Butt contacts that handle high
Inrush spikes
Independent or Dependent lamp circuitry
Industry standard size mounting hole
Typical Applications:
Appliance
Food Service
Transportation
General Purpose
Carling Technologies, Inc.
60 Johnson Avenue, Plainville, CT
06062
Email:
sales
@
carlingtech.com
Application Support:
team2
@
carlingtech.com
Phone:
860.793.9281
Fax:
860.793.9231
www.carlingtech.com
2 |
622/632-Series Small-Sized Rocker Switches - General Specifications, Ordering Scheme, Dimensional Specifications
Dielectric Strength
UL/CSA:
1000V-live to dead metal parts
& opposite polarity
50,000 cycles
Mechanical Life
100,000 cycles
Operating Temperature
32°F to 185°F (0°C to 85°C)
Electrical Life
1
Base Part Number
632121
2
Actuator
Color
1 B
3
Base
Color
4
Lamp
K N
5
Legend
BASE PART NUMBER: SERIES / CIRCUITRY / RATING / TERMINATION
8A 250VAC; 12A 125VAC; 1/2 HP 125-250VAC
622-SERIES NON-ILLUMINATED ROCKER
ON-none-OFF (Single Pole)
ON-none-OFF (Double Pole)
632-SERIES ILLUMINATED ROCKER
ON-none-OFF (Single Pole, dependent lamp) schematic 1
ON-none-OFF (Single Pole, independent lamp) schematic 3
ON-none-OFF (Single Pole, independent lamp unballasted) schematic 5
ON-none-OFF (Double Pole, dependent lamp with 5 terms.) schematic 2
ON-none-OFF (Double Pole, dependent lamp with 4 terms.) schematic 4
3 ACTUATOR COLOR
3
622 (non illuminated)
B
Black
W
White
632 (illuminated)
1
Clear Amber
2
Clear Red
3
Clear Blue
2
4
Clear Green
5
Clear
Solder Lugs
622121
622221
632121
632321
632521
632221
632421
.187 Tabs
622122
622222
632122
632322
632522
632222
632422
A
C
E
H
J
K
6V incandescent
12V incandescent
18V incandescent
24V incandescent
125V neon
250V neon
4 LAMP VOLTAGE / STYLE
1
N
622 (non illuminated)
1
unballasted LED
2
6V LED
3
12V LED
4
24V LED
5 ROCKER LEGEND
N
NO Legend
A
OFF-ON vertical
B
OFF-ON horizontal
D
I-O horizontal
E
I-O vertical
F
O on rocker radius
3 BASE COLOR
3
B
Black
W
White
Notes:
1
For all incandescent or LED lamps specify 5 in 5th digit of part number.
Example 632151-1B-CN
2
Available with incandescent lamps only.
3
Additional colors available. Consult factory for details.
.187[4.74] X
.032[812]
.150[3.81]
.825[20.96]
.590[14.99]
.080[2.03]
.405[10.29]
.125[3.17]
DIA
.315[8.00]
.187 TAB (Q.C)
.945[24.00]
.630[16.00]
.315[8.00]
.187 SOLDER LUG
TERMINAL TYPE
RECOMMENDED
PANEL
OPENING
+.000[.00]
-.004[.10]
A
.505[12.83]
632 SCHEMATIC
3
5
6
2
1
+.004[.10]
-.000[.00]
UNBALLASTED
1
2
5
6
2
1
+2
3
3
5
6
1
2
+3
4
5
6
1
2
3
5
+5
PANEL
THICKNESS
.030[.76]-.050[1.27]
.050[1.27]-.078[1.98]
.078[1.98]-.125[3.17]
B
1
2
+3
1
A
.508[12.90]
.508[12.90]
.508[12.90]
B
.756[19.20]
.764[19.40]
.780[19.81]
BOTTOM VIEW OF
TERMINAL ARRANGEMENT
+3
*Manufacturer reserves the right to change product specification without prior notice.
Email: sales
@
carlingtech.com Application Support: team2@carlingtech.com
Phone: (860) 793–9281 Fax: (860) 793–9231
www.carlingtech.com
