SAW Components
SAW RF filter
Data sheet
Application
s
s
s
s
s
B1646
2326.25 MHz
Low-loss RF filter for digital radio
Very low insertion attenuation
Low amplitude ripple
Usable passband 12.5 MHz
no matching network required
Features
s
s
s
s
s
s
s
s
Package size 3.0 x3.0 x 1.1 mm
3
Package code DCC6C
RoHS compatible
Approximate weight 0.037 g
Package for
Surface Mount Technology
(SMT)
Ni, gold-plated terminals
AEC-Q200 qualified component family
Electrostatic Sensitive Device
(ESD)
Pin configuration
s
5
Input
s
2
Output
s
1,3,4,6 To be grounded
Please read
cautions and warnings and
important notes
at the end of this document.
2
May 29, 2013
SAW Components
SAW RF filter
Data sheet
Characteristics
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –20 ˚C to +85 ˚C
Z
S
=
50
Ω
Z
L
=
50
Ω
min.
Nominal frequency
Maximum insertion attenuation
2320.0 ... 2332.5
Amplitude ripple
(p-p)
2320.0 ... 2332.5
Input return loss
Output return loss
Attenuation
50.0
... 2175.0
2227.0
2400.0
2500.0
... 3000.0
MHz
MHz
MHz
MHz
MHz
α
27
19
12
23
27
34
26
18
29
34
—
—
—
—
—
f
N
α
max
MHz
∆α
MHz
—
10.0
10.0
0.6
16.0
15.0
1.5
—
—
—
2.5
3.5
—
typ.
@ 25 ˚C
2326.25
max.
—
B1646
2326.25 MHz
MHz
dB
dB
dB
dB
2700.0
dB
dB
dB
dB
dB
Group delay ripple
(p-p)
2320.0 ... 2332.5
MHz
—
5
15
ns
Please read
cautions and warnings and
important notes
at the end of this document.
3
May 29, 2013
Embedded System
