CN
features
A
EU
resistors
convex termination with scalloped corners
resistor array
Manufactured to type RK73 standards
Less board space than individual chips
Isolated resistor elements
Convex terminations with scalloped corners
Marking: Marked with resistance value
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
•
AEC-Q200 Qualified: CN1J4A only
•
•
•
•
•
•
dimensions and construction
a
W
C
t
Protective
Coating
Electrode
Resistive
Film
Ceramic
Substrate
d
L
p
b
Size
Code
1J4A
2B4A
L
W
Dimensions
inches
(mm)
C
d
t
a
b
p (ref.)
.031
(0.8)
.050
(1.27)
.126±.006 .063±.006 .012±.008 .010±.004 .020±.004 .020±.006 .012±.004
(3.2±0.15) (1.6±0.15) (0.3±0.2) (0.25±0.1) (0.5±0.1) (0.5±0.15) (0.3±0.1)
0.2±.008 .122±.008 .020±.008 .014±.006 .022±.004 .031±.008 .018±.004
(5.1±0.2) (3.1±0.2) (0.5±0.2) (0.35±0.15) (0.55±0.1) (0.8±0.2) (0.45±0.1)
ordering information
New Part #
CN
Type
1J
Size
1J
2B
4
Elements
A
Terminal
Convex
T
Termination
Material
T: Sn
(Other termination
styles maybe
available, please
contact factory
for options)
TD
Packaging
TE: 7" embossed
plastic
TD: 7" paper tape
TED: 10" embossed
plastic
TDD: 10" paper tape
101
Nominal
Resistance
2 significant figures
+ 1 multiplier for
±2% & ±5%
3 significant figures
+ 1 multiplier for
±1%
J
Tolerance
F: ±1%
J: ±5%
circuit schematic
R1 R2 R3 R4
For further information on packaging,
please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
12/17/13
130
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
convex termination with scalloped corners
resistor array
applications and ratings
Part
Designation
CN1J4A
CN2B4A
Power Rating
@ 70°C
(Per Element)
1/16W (.063W)
1/8W (.125W)
Rated
Ambient
Temp.
70°C
Rated
Terminal
Temp.
+125°C
T.C.R. (ppm/°C) Max.
(F±1%)
(J±5%)
Resistance Range
E-24, E-96
(F±1%)
E-24
(J±5%)
Absolute
Maximum
Working
Voltage
50V
200V
Absolute
Maximum
Overload
Voltage
100V
400V
Operating
Temp.
Range
-55°C to
+155°C
±100:R≥10Ω ±200:R≥10Ω 10 - 100kΩ 1Ω - 1MΩ
±400:R<10Ω
–––
–––
10Ω - 1MΩ
* Note that network resistors generate higher heat rather than single flat chip resistors even under rated power output
If any questions should arise whether to use the “Rated Ambient Temperature” or the “Rated Terminal Part Temperature,” please give priority
to the “Rated Terminal Part Temperature.” Prior to use and for more details refer to “Introduction of the derating curves on the terminal part
temperature” in the beginning of the catalog.
environmental applications
Derating Curve
100
80
% Rated Power
60
40
20
0
-60 -40 -20
-55
% Rated Power
CN1J4A (155°C)
CN2B4A (155°C)
100
CN1J4A
80
60
40
20
0
-60 -40 -20
-55
0
60 80 100 120 140 160 180
70
155
Ambient Temperature
(°C)
40
20
0
60 80 100 120 140 160 180
70
125
155
Terminal Part Temperature
(°C)
40
20
For resistors operated at an ambient temperature of 70°C or above, a power
rating shall be derated in accordance with the above derating curve.
Circuit Board Application
For resistors operated at a terminal part temperature of described for each size
or above, a power rating shall be derated in accordance with the derating curve.
Please refer to “Introduction of the derating curve based on the terminal part
temperature” in the beginning of our catalog before use.
Vcc
IC
IC
Performance Characteristics
Parameter
Resistance
T.C.R.
Overload (Short time)
Resistance to Solder Heat
Rapid Change of Temperature
Moisture Resistance
Endurance at 70°C
High Temperature Exposure
Requirement
∆
R ±%
Limit
Typical
Within specified
—
tolerance
Within specified
—
T.C.R.
±2.0%
±0.25%
±1.0%
±0.75%
±1.0%
±0.5%
±5.0%
±1.0%
±5.0%
±0.5%
±1.0%
±0.25%
Test Method
25°C
+25°C/-55°C, +25°C/+125°C
Rated voltage x 2.5 for 5 seconds
260°C ± 5°C, 10 seconds ± 1 second
-55°C (30 minutes), +125°C (30 minutes), 5 cycles
40°C ± 2°C, 90 - 95% RH, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
+155°C, 1000 hours
11/28/16
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
131
