Confidential Document
2.
Rev
B
RECORD OF REVISION
Date
JAN/20/99
Item
8,15
Page
9,19
Comment
Correction pin definition on pin1 & 2.
Original Pin1=VSS, Pin2=VDD,
change Pin1=VDD, Pin2=VSS.
1. Change Outline Drawing.
2. Package Information.
1. Change VDD from 4.7V~5.5V to
2.7V~ 5.5V.
Change: P/N from GM12322S1L3YH-J2 to
GM123210SFSYB-01
C
D
MAY/09/01 3,15,16
OCT/17/01
JUL/16/02
5,7
13
3,19,20
5,8
17
Page:
2 /20
Confidential Document
3. GENERAL SPECIFICATION
Display Format :
Dot Size :
Dot Pitch
View Area :
General Dimensions :
Weight :
LCD Type :
122dots (W)
×
0.4 (W)
×
0.44 (W)
×
60.6 (W)
×
65.4 (W)
×
10 g max.
STN Gray
V STN Yellow
FSTN
32dots (H)
0.45 (H) mm
0.49 (H) mm
20.0 (H) mm
30 (H)
×
6 (T) mm Max.
Polarizer mode :
Reflective
V Transflective
Transmissive
Negative
View Angle :
V 6 O’clock
12 O’clock
Others
Backlight :
V LED
EL
CCFL
Backlight Color :
V Yellow green
Amber
Blue Green
White
Controller / Driver :
Temperature Range :
SED1520D0A
Others
Normal
V Wide Temperature
Operating 0 to 50°C
Operating -20 to 70°C
Storage -20 to 70°C
Storage
-30 to 80°C
Page:
3 /20
Confidential Document
4. ABSOLUTE MAXIMUM RATINGS
4.1
ELECTRICAL ABSOLUTE MAXIMUM RATINGS
V
SS
= 0V,
Item
Supply Voltage
(Logic)
Supply Voltage
(LCD Driver)
Input Voltage
Operating Temperature
Storage Temperature
Symbol
V
DD
-V
SS
V
DD
-V
EE
V
I
T
OP
T
STG
Min.
0
0
V
SS-0.3
-20
-30
Max.
8
16.5
V
DD+0.3
70
80
Ta = 25°C
Unit
V
V
V
°C
°C
4.2
Item
ENVIRONMENTAL ABSOLUTE MAXIMUM RATINGS
Operating
(Min.)
Max.)
70
Storage
Comment
(Min.)
-30
Note(2)
2
2
(Max.)
80
Note (1)
Without Condensation
2
Ambient Temp
Humidity
Vibration
Shock
-20
Note (2)
--
--
4.9M/S
--
--
19.6M/S
490M/S
XYZ Direction
XYZ Direction
29.4M/S
2
Note(1) Ta =
0°C
: 50Hr Max.
Note(2) Ta
≤
40°C : 90% RH Max.
Ta
≥
40°C : Absolute humidity must be lower than the humidity
of 90% RH at 40°C.
Page:
4 /20
Confidential Document
5. ELECTRICAL CHARACTERISTICS
Item
Supply Voltage
(Logic)
Supply Voltage
(LCD)
Symbol
V
DD
-V
SS
-20°C
V
DD
-V
EE
25°C
70°C
V
IH
Input Voltage
V
IL
Logic Supply
Current
I
DD
V
DD
-V
SS
=5V
--
V
SS
--
--
1.2
V
SS+0.8
--
mA
Condition
Min.
2.7
6.9
5.8
4.8
V
SS+2.0
Typ.
5.0
7.5
6.4
5.3
--
Max.
5.5
8.1
6.9
5.8
V
DD
V
V
Unit
V
6. ELECTRO-OPTICAL CHARACTERISTICS
ITEM
Rise Time
Symbol
Tr
25°C
0°C
Fall Time
Contrast
View Angle
Frame Frequency
Tf
25°C
CR
θ1~θ2
∅1, ∅2
Ff
25°C
25°C &
CR≥1.5
25°C
3
--
-30
--
--
200
4
--
--
64
350
--
80
Note (2)
30
--
Hz
Note (3)
Condition
0°C
--
120
--
240
Note (1)
--
ms
Min.
Typ.
--
Max.
--
ms
Unit
Ref.
Note (1) & (2) : See next page
Note (3) : Contrast ratio is defined under the following condition:
CR= Brightness of non-selected condition
Brightness of selected condition
( a ).
( b ).
( c ).
( d ).
Temperature ---------- 25°C
Frame frequency ---- 64Hz
Viewing angle --------
θ=
0°,
∅
= 0°
Operating voltage --- 6.4V
Page:
5 /20
