REV.
DESCRIPTION
DATE
APPROVED
Ø0.045 [Ø1.1mm]
TYP.
A
B
C
D
E
Engineering Release.
TYPO Correction.
Release for Re-Tool.
Release for Quotation.
Production Release.
03/07/03
03/14/03
11/10/03
02/19/04
03/26/04
M. C.
M. C.
M. C.
M. C.
M. C.
A
D
E
307-500
F
B
C
304-300
PART NO.
300-100-022
300-100-030
300-100
300-100-075
301-150CS
301-150-030
301-150-040
301-150
301-150 MOD
302-200-030
302-200-040
302-200
303-250
304-300
305-350
306-400
307-500
A
.100 (2.5mm)
.150 (3.8mm)
.200 (5.1mm)
.250 (6.4mm)
.300 (7.5mm)
.350 (8.9mm)
.400 (10.2mm)
.500 (12.7mm)
B
N.A.
.030 (.76mm)
.045 (1.1mm)
.075 (1.9mm)
N.A.
.030 (.76mm)
.040 (1.0mm)
.045 (1.1mm)
.045 (1.1mm)
.030 (.76mm)
.040 (1.0mm)
.045 (1.1mm)
.045 (1.1mm)
.045 (1.1mm)
.045 (1.1mm)
.045 (1.1mm)
.045 (1.1mm)
C
.022 (.55mm)
.011 (.28mm)
.022 (.55mm)
.022 (.55mm)
.022 (.55mm)
.011 (.28mm)
.022 (.55mm)
.022 (.55mm)
.022 (.55mm)
.011 (.28mm)
.022 (.55mm)
.022 (.55mm)
.026 (.66mm)
.026 (.66mm)
.030 (.76mm)
.030 (.76mm)
.030 (.76mm)
D
N.A.
.050 (1.3mm)
.050 (1.3mm)
.055 (1.4mm)
N.A.
.090 (2.3mm)
.090 (2.3mm)
.090 (2.3mm)
.090 (2.3mm)
.140 (3.6mm)
.140 (3.6mm)
.190 (4.8mm)
.190 (4.8mm)
E
.180 (4.6mm)
.180 (4.6mm)
.270 (6.9mm)
.270 (6.9mm)
.240 (6.1mm)
.290 (7.4mm)
F
.090 (2.3mm)
.090 (2.3mm)
.125 (3.2mm)
.125 (3.2mm)
.090 (2.3mm)
.090 (2.3mm)
300-100
301-150
302-200
.340 (8.6mm)
.390 (9.9mm)
.440 (11.2mm) .090 (2.3mm)
.490 (12.4mm)
.590 (15.0mm)
STANDARD TOLERANCE
( UNLESS OTHERWISE SPECIFIED )
DECIMALS
ANGULAR
®
2. MATERIAL: NYLON 6/6, 94V-2, NATURAL. BIVAR MATERIAL CODE 03-NL.
BASF ULTRAMID NYLON 6/6 A3K NATURAL.
1. GENERAL SPECIFICATIONS: BIVAR MOLDED COMPONENT SPECIFICATION BV00-E101.
.X
.XX
.XXX
DESIGNED:
± .1
± .01
± .005
X°
± 1°
4 THOMAS, IRVINE, CA. 92618
TEL: (949) 951-8808
FAX: (949) 951-3974
TITLE:
DATE:
CAPACITOR MOUNT,
300 SERIES
REVISION:
PART NO:
Michael Chen
CHECKED:
03/07/03
DATE:
30X-XXX-XXX
E
D. Green
03/07/03
CAGE CODE : 32559
SHEET #
1
OF
1
CAD GENERATED DOCUMENT, DO NOT MEASURE DRAWING.
