MALE PCB
PINS
SOLDER TERMINALS VARIOUS TYPES
2709
.081 DIA.
HOLE
.111 DIA.
.156 DIA.
2709-X-07-XX-00-00-07-0
Swage mount in .116 hole
8602
Basic
Part
Number
Board
Thick-
ness
Length
V
Length
A
8602-1-00-XX-00-00-07-0
Square press-fit in .032 plated through-hole
.050 DIA.
.035 DIA.
.080
.260
2115
2115-2-00-XX-00-00-07-0
Swage mount in .043 hole
For a .062 thick board
.022 DIA.
HOLE
.039 DIA.
.062 DIA.
.039 DIA.
.080
.020
.080
.068
V
.088 DIA.
.020 .230
.118 DIA.
.064 DIA.
HOLE
.030
A
2709-2
2709-3
.062
.094
.109
.141
.281
.250
.040 DIA.
.140
.028
SQUARE
.025 DIA.
.050
.100
HOLE TAPERING DOWN TO .050 DIA.
2326
.033 DIA.
HOLE
.050 DIA.
.078 DIA.
.050 DIA.
2326-2-00-XX-00-00-07-0
Swage mount in .055 hole
For a .062 thick board
8831
.072 DIA.
.060 DIA.
8831-0-00-XX-00-00-03-0
Press-fit in .057 mounting hole
8835
.072 DIA.
8835-0-00-XX-00-00-03-0
Press-fit in .057 mounting hole
8836
.093 DIA.
8836-0-00-XX-00-00-03-0
Press-fit in .075 mounting hole
.030
.028
.050
.242
.060 DIA.
.053 DIA.
.040 DIA.
.030
.028
.054
.078 DIA.
.030
.028
.020
.090
.053 DIA.
.242
.025 DIA.
.072 DIA.
.312
.090
0912/7912
.072 DIA.
.060 DIA.
0912-0-00-XX-00-00-03-0
Press-fit in .057 mounting hole
.031
.032
3080
Basic Part
Number
Pin
Length
A
.039 DIA.
HOLE
3080-0-01-XX-00-00-03-0
Press-fit in .057 mounting hole
For wire sizes up to 22 AWG
.072 DIA.
.100
A
.053 DIA.
0912-0
7912-0
.313
.510
.126 .138
.180
.060 DIA.
.053 DIA.
.020 DIA.
.020
.125
PAGE 244 | MALE PCB PINS
SPECIFICATIONS:
Pin Material:
Brass Alloy 360, 1/2 Hard
( Swage pins are annealed )
Dimensions: Inches
Tolerances On:
Lengths: ± .005
Diameters: ± .002
Angles:
±2°
ORDER CODE: XXXX - X - XX -
XX
- 00 - 00 - XX - 0
BASIC PART #
SPECIFY PIN FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
44
300
μ”
SILVER OVER COPPER (RoHS)
50
300
μ”
ELECTRO-SOLDER
(60/40 SnPb)
2011/65/EU
RoHS - 2
