65043-032LF

Description
Headers u0026 Wire Housings MINI-LATCH PV 3P
CategoryThe connector
File Size330KB,16 Pages
ManufacturerFCI [First Components International]
Download Datasheet Parametric View All

65043-032LF Online Shopping

Suppliers Part Number Price MOQ In stock
65043-032LF - - View Buy Now

65043-032LF Overview

Headers u0026 Wire Housings MINI-LATCH PV 3P

65043-032LF Parametric

Parameter NameAttribute value
Product CategoryHeaders & Wire Housings
ManufacturerFCI [First Components International]
RoHSDetails
ProductWire Housings
TypeReceptacle Housing
Number of Positions10 Position
Pitch2.54 mm
Number of Rows2 Row
Mounting StyleWire
Termination StyleCrimp
Mounting AngleStraight
Contact GenderSocket (Female)
PackagingBulk
Housing MaterialPolyphenylene Ether (PPE)
Factory Pack Quantity1000
Voltage Rating1 kV
Wire Gauge36-22
TYPE
NUMBER
PRODUCT SPECIFICATION
TITLE
PAGE
BUS-12-067
REVISION
Crimp-to Wire, Mini-PV™ Receptacles and Mini-Latch Housings
1 of 16
AUTHORIZED BY
DATE
K
31-May-06
H.T. Brewbaker
CLASSIFICATION
UNRESTRICTED
1.0
OBJECTIVE
This specification defines the performance, test, quality and reliability requirements of Crimp-to-Wire Mini-
PV (TM) receptacles and Mini-Latch housings.
2.0
SCOPE
This specification is applicable to the termination characteristics of the Crimp-to-Wire Mini-PV (TM) receptacles
and Mini-Latch housings which are designed for interconnection of discrete wires and
0.025 inch round or square pins.
These connectors provide only the receptacle half of the interconnection and are designed to mate with
single or double rows of pins, free standing or in headers, on 0.100, 0.125, 0.150 or 0.156 inch centers.
3.0
GENERAL
This document is composed of the following sections:
Paragraph
1.0
2.0
3.0
4.0
5.0
5.1
5.2
5.3
5.4
6.0
7.0
8.0
9.0
9.1
9.2
9.3
9.4
9.5
9.6
TABLE VI
3.1 Banned/Restricted Substances
All product where the part number ends in “LF” meet the European Union directives and other
country regulations as described in GS-22-008. The part numbers that do not end in “LF” meet all
regulations except for Pb in SnPb plating, if available. Tin plated “LF” product has 100% tin plating
in the interface and has not been tested for whisker growth in all interconnect environments.
Title
OBJECTIVE
SCOPE
GENERAL
APPLICABLE DOCUMENTS
REQUIREMENTS
Qualification
Material
Finish
Design and Construction
ELECTRICAL CHARACTERISTICS
MECHANICAL CHARACTERISTICS
ENVIRONMENTAL CONDITIONS
QUALITY ASSURANCE PROVISIONS
Equipment Calibration
Inspection Conditions
Sample Quantity and Description
Acceptance
Qualification Testing
Requalification Testing
QUALIFICATION TEST MATRIX
Copyright
Form E-3334
Rev E
FCI
GS-01-001
PDM: Rev:K
STATUS:
Released
Printed: Nov 28, 2010
.
