Part Number:
Status:
Overview:
Description:
5041892470
Active
Micro-Lock™ Connectors
Micro-Lock™ 1.25mm Pitch Dual-Row Right-Angle Header, Beige, 24 Circuits,
5041892470
Documents:
3D Model
Drawing (PDF)
Product Specification PS-504186-001-001 (PDF)
Application Specification AS-504186-001-001 (PDF)
General
Product Family
Series
Application
Overview
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Compliant
Guide to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Application Specification AS-504186-002-001 (PDF)
Packaging Specification SPK-504189-001-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
PCB Headers
504189
Wire-to-Board
Micro-Lock™ Connectors
Micro-Lock
887191185583
No
24
24
Beige
30
No
No
No
Yes
Brass
Tin
Nickel
1166.342/mg
2
Right Angle
3.00mm
No
None
1.20mm, 1.60mm
Embossed Tape on Reel
1.25mm
1.25mm
-25°C to +85°C
Surface Mount
1.5A
50V
Search Parts in this Series
504189 Series
Mates With
504186 Micro-Lock™ Wire-to-Board Crimp
Housing
AS-504186-001-001, AS-504186-002-001
SPK-504189-001-001
PS-504186-001-001
SD-504189-001, SD-504189-002
