384063 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> 384063

Preview

384063: DescriptionDIN 41612 Connectors 96P 2.54MM RA MALE TYPE C 12MM THR; CategoryThe connector The connector; File Size62KB，2 Pages; ManufacturerERNI; Websitehttp://www.erni.com; Environmental Compliance

Download Datasheet Parametric View All

384063 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	384063	-	-	View	Buy Now

384063 Overview

DIN 41612 Connectors 96P 2.54MM RA MALE TYPE C 12MM THR

384063 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	ERNI
Reach Compliance Code	compliant
Samacsys Description	DIN41612 male 2.54mm type C 96 way ERNI ERNIPRESS Series 96 Way 2.54mm Pitch, Type C Class C2, 3 Row a/b/c, Right Angle DIN 41612 Connector, Plug, Solder
Other features	STANDARDS: DIN EN 60603-2; IEC 60603-2
Connector type	BOARD EURO CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	YES
Filter function	NO
IEC compliance	YES
MIL compliance	NO
Manufacturer's serial number	384063
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	3
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	96

Preview

Download Datasheet

View All

2,5

-0,2

c32

85,5

c1

Stecklänge / mating length

+0,2

max.11,1

ESL

2x2,54=5,08

8,7

a32

max.94

31x2,54=78,74

2,54

a1

6

±0,1

3

-0,4

0,6

3,95

E =

early mate, late break

/ voreilend

S = standard

L = late mate, early break / nacheilend

12,7

10,2

-0,2

5,08

Datum

2,5

+0,1

date

Anforderungsstufe/

class

87,5

88,9

Stecklänge

mating length

Bestückungsplan /

contact layout

32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1

S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S

c

b

a

THR /

through hole reflow

Bauart 4 / t

ype 4

Anforderungsstufe 2 = 400 Steckzyklen

/ performance class 2 = 400 mating cycles

Fehlende Maße und Angaben nach IEC 60 603-2 / DIN EN 60 603-2

3

+0,1

XXXXXXX

ERNI

RC 2

6,4

-0,1

2,54

a b c

Missing information and dimensions per IEC 60 603-2 / DIN EN 60 603-2

Leiterplatten-Lochbild /

PCB drillhole pattern

2,8

2 x 2,54 (= 5,08)

+0,1

1

±0,1

0,05

alle Löcher/

all holes

Copyright by ERNI GmbH

Proprietary notice pursuant to ISO 16016 to be observed.

c

b

a

32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1

2,54

5,3

±0,1

2,54

31 x 2,54 (=78,74)

88,9

Information:

Tolerances

All Dimensions

in mm

Scale

2:1

Only for Information.

To ensure that this is the latest

version of this drawing, please

contact one of the ERNI companies

before using.

a

Index

23.09.2013

Date

Designation

Subject to modification without

prior notice.

Drawing will not be updated.

Messerleiste C 96 THR

Male Connector C96 THR

www.ERNI.com

Class

384063

STVC

4,8

±0,2

0,8

±0,1

0,8

±0,1

I

A3
