Part Number:
Status:
Overview:
Description:
0461141233
Active
EXTreme LPHPower™ Connectors
1.27mm, 12.00mm Pitch, EXTreme LPHPower Receptacle Header, Vertical, Compliant
Pin, 12 Power Contacts, 32 Signal Contacts, Select Gold (Au) Plating, without BMI
Guides
Documents:
3D Model
Drawing (PDF)
Product Specification PS-46114-001-001 (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
Application Tooling Part Link
Application Tooling Part Link
Comments
Overview
Product Name
UPC
Physical
(p)ower-(s)ignal Configuration
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Application Specification AS-46114-001-001 (PDF)
Packaging Specification PK-46114-003 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Reviewed
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
LR19880
E29179
PCB Receptacles
46114
Board-to-Board, Power
62100-6300
62201-8672
Press Fit Pin
EXTreme LPHPower™ Connectors
EXTreme LPHPower
756054922927
12p - 32s
44
44
Black
250
94V-0
No
No
None
None
High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
15.148/g
2
Vertical
No
None
Tray
1.27mm, 12.00mm
1.27mm, 2.50mm
0.762µm
2.540µm
Yes
Yes
No
Yes
-40°C to +105°C
Search Parts in this Series
46114 Series
Mates With
45985 EXTreme LPHPower Header
Termination Interface: Style
Electrical
Current - Maximum per Contact
Grounding to PCB
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Through Hole - Compliant Pin
30.0A
No
250V AC (RMS)/DC
AS-46114-001-001
PK-46114-003
PS-46114-001-001
SD-46114-120
