Green
B270 - B2100
2.0A HIGH VOLTAGE SCHOTTKY BARRIER RECTIFIER
Features
•
•
•
•
•
•
•
•
Schottky Barrier Chip
Guard Ring Die Construction for Transient Protection
Low Power Loss, High Efficiency
Surge Overload Rating to 50A Peak
For Use in Low Voltage, High Frequency Inverters, Free
Wheeling, and Polarity Protection Application
High Temperature Soldering: 260°C/10 Second at Terminal
Lead Free Finish/RoHS Compliant (Note 1)
Green Molding Compound (No Halogen and Antimony)
(Note 2)
Mechanical Data
•
•
•
•
•
•
Case: SMB
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Lead Free Plating (Matte Tin Finish). Solderable per
MIL-STD-202, Method 208
Polarity: Cathode Band or Cathode Notch
Weight: 0.093 grams (approximate)
Top View
Bottom View
Ordering Information
(Note 3)
Part Number
B2xxx-13-F
Notes:
Case
SMB
Packaging
3000/Tape & Reel
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see
EU Directive 2002/95/EC Annex Notes.
2. Product manufactured with Data Code 0924 (week 24, 2009) and newer are built with Green Molding Compound.
3. For packaging details, go to our website at http://www.diodes.com.
Marking Information
YWW
xxxx(x)
XXXX = Product type marking code, ex: B290 (SMB package)
= Manufacturers’ code marking
YWW = Date code marking
Y = Last digit of year (ex: 2 for 2002)
WW = Week code (01 to 53)
B270 - B2100
Document number: DS30021 Rev. 11 - 2
1 of 4
www.diodes.com
September 2011
© Diodes Incorporated
B270 - B2100
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@ T
T
= 125°C
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
B270
70
49
B280
80
56
2.0
50
B290
90
63
B2100
100
70
Unit
V
V
A
A
Thermal Characteristics
Characteristic
Typical Thermal Resistance Junction to Terminal (Note 4)
Operating and Storage Temperature Range
Symbol
R
θ
JT
T
J,
T
STG
Value
15
-65 to +150
Unit
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Forward Voltage Drop
Leakage Current (Note 5)
Total Capacitance
Notes:
4. Valid provided that terminals are kept at ambient temperature.
5. Short duration pulse test used to minimize self-heating effect.
Symbol
V
F
I
R
C
T
Min
-
-
-
-
Typ
-
-
-
-
Max
0.79
0.69
7.0
2.0
75
Unit
V
μA
mA
pF
Test Condition
I
F
= 2.0A, T
A
= 25°C
I
F
= 2.0A, T
A
= 100°C
@ Rated V
R
, T
A
= 25°C
@ Rated V
R
, T
A
= 100°C
V
R
= 4V, f = 1MHz
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
10
1.0
T
j
= 125°C
T
j
= 100°C
0.1
T
j
= 25°C
0.01
0
0.2
0.4
0.6
0.8
1.0
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
B270 - B2100
Document number: DS30021 Rev. 11 - 2
2 of 4
www.diodes.com
September 2011
© Diodes Incorporated
B270 - B2100
1,000
2.5
I
F(AV)
, AVERAGE FORWARD CURRENT (A)
1
10
100
V
R
, DC REVERSE VOLTAGE (V)
Fig. 3 Total Capacitance vs. Reverse Voltage
C
T
, TOTAL CAPACITANCE (pF)
2.0
1.5
100
1.0
0.5
10
0.1
0
25
50
75
100
125
T
T
, TERMINAL TEMPERATURE (
°
C)
Fig. 4 Forward Current Derating Curve
150
50
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
Single Half-Sine-Wave
40
30
20
10
0
10
100
NUMBER OF CYCLES AT 60 Hz
Fig. 5 Max Non-Repetitive Peak Forward Surge Current
1
Package Outline Dimensions
B
SMB
Dim
Min
Max
A
3.30
3.94
B
4.06
4.57
C
1.96
2.21
D
0.15
0.31
E
5.00
5.59
G
0.05
0.20
H
0.76
1.52
J
2.00
2.50
All Dimensions in mm
A
C
D
J
H
G
E
B270 - B2100
Document number: DS30021 Rev. 11 - 2
3 of 4
www.diodes.com
September 2011
© Diodes Incorporated
B270 - B2100
Suggested Pad Layout
Dimensions Value (in mm)
Z
6.7
G
1.8
X
2.3
Y
2.5
C
4.3
