BAV200, BAV201, BAV202, BAV203
www.vishay.com
Vishay Semiconductors
Small Signal Switching Diodes, High Voltage
FEATURES
• Silicon epitaxial planar diodes
• AEC-Q101 qualified
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
• General purposes
MECHANICAL DATA
Case:
QuadroMELF SOD-80
Weight:
approx. 34 mg
Cathode band color:
black
Packaging codes/options:
GS18/10K per 13" reel (8 mm tape), 10K/box
GS08/2.5K per 7" reel (8 mm tape), 12.5K/box
PARTS TABLE
PART
BAV200
BAV201
BAV202
BAV203
TYPE
DIFFERENTIATION
V
RRM
= 60 V
V
RRM
= 120 V
V
RRM
= 200 V
V
RRM
= 250 V
ORDERING CODE
BAV200-GS18 or BAV200-GS08
BAV201-GS18 or BAV201-GS08
BAV202-GS18 or BAV202-GS08
BAV203-GS18 or BAV203-GS08
TYPE
MARKING
-
-
-
-
INTERNAL
CONSTRUCTION
Single
Single
Single
Single
REMARKS
Tape and reel
Tape and reel
Tape and reel
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
TEST CONDITION
PART
BAV200
Repetitive peak reverse voltage
BAV201
BAV202
BAV203
BAV200
Reverse voltage
BAV201
BAV202
BAV203
Forward continuous current
Peak forward surge current
Repetitive peak forward current
Power dissipation
t
p
= 1 s, T
j
= 25 °C
f = 50 Hz
SYMBOL
V
RRM
V
RRM
V
RRM
V
RRM
V
R
V
R
V
R
V
R
I
F
I
FSM
I
FRM
P
tot
VALUE
60
120
200
250
50
100
150
200
250
1
625
500
UNIT
V
V
V
V
V
V
V
V
mA
A
mA
mW
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
Junction temperature
Storage temperature range
TEST CONDITION
On PC board
50 mm x 50 mm x 1.6 mm
SYMBOL
R
thJA
T
j
T
stg
VALUE
500
175
- 65 to + 175
UNIT
K/W
°C
°C
Rev. 1.7, 31-Jul-12
Document Number: 85544
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAV200, BAV201, BAV202, BAV203
www.vishay.com
Vishay Semiconductors
TEST CONDITION
I
F
= 100 mA
V
R
= 50 V
V
R
= 100 V
V
R
= 150 V
V
R
= 200 V
T
j
= 100 °C, V
R
= 50 V
T
j
= 100 °C, V
R
= 100 V
T
j
= 100 °C, V
R
= 150 V
T
j
= 100 °C, V
R
= 200 V
I
R
= 100 μA, t
p
/T = 0.01,
t
p
= 0.3 ms
V
R
= 0, f = 1 MHz
I
F
= 10 mA
BAV200
BAV201
BAV202
BAV203
BAV200
BAV201
BAV202
BAV203
BAV200
BAV201
BAV202
BAV203
PART
SYMBOL
V
F
I
R
I
R
I
R
I
R
I
R
I
R
I
R
I
R
V
(BR)
V
(BR)
V
(BR)
V
(BR)
C
D
r
f
t
rr
60
120
200
250
1.5
5
50
MIN.
TYP.
MAX.
1
100
100
100
100
15
15
15
15
UNIT
V
nA
nA
nA
nA
μA
μA
μA
μA
V
V
V
V
pF
ns
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Forward voltage
Reverse current
Breakdown voltage
Diode capacitance
Differential forward resistance
Reverse recovery time
I
F
= I
R
= 30 mA, i
R
= 3 mA,
R
L
= 100
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
r
f
- Differential Forward Resistance (
Ω
)
1000
100
Scattering Limit
10
1000
I
R
- Reverse Current (µA)
100
1
V
R
=
V
RRM
T
j
= 25 °C
10
0.1
0.01
0
40
80
120
160
200
1
0.1
1
10
100
94 9084
T
j
- Junction Temperature (°C)
94 9089
I
F
- Forward Current (mA)
Fig. 1 -
Reverse Current vs. Junction Temperature
Fig. 3 -
Differential Forward Resistance vs. Forward Current
1000
T
j
= 25 °C
I
F
- Forward Current (mA)
100
Scattering Limit
10
1
0.1
0
94 9085
0.4
0.8
1.2
1.6
2.0
V
F
- Forward
Voltage
(V)
Fig. 2 -
Forward Current vs. Forward Voltage
Rev. 1.7, 31-Jul-12
Document Number: 85544
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAV200, BAV201, BAV202, BAV203
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
QuadroMELF SOD-80
Vishay Semiconductors
(0
1.
7
1.6 (0.063)
1.4 (0.055)
0.47 (0.019) max.
3.7 (0.146)
3.3 (0.130)
The gap between plug and glass can
be either on cathode or anode side
Foot print recommendation:
1.25 (0.049) min.
2.5 (0.098) max.
glass
.0
> R3 (R0.118)
gl
as
s
67
Cathode identification
)
5 (0.197) ref.
96 12071
Rev. 1.7, 31-Jul-12
Document Number: 85544
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
2 (0.079) min.
