BAS16T
BAW56T
BAV70T
BAV99T
150mW 85Volt
Switching Diode
•
•
Halogen
free available upon request by adding suffix "-HF"
Ultra-Small Surface Mount Package
For General Purpose Switching Applications
High Conductance
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
BAS16T
Marking : A2
BAW56T
Marking : JD
BAV70T
Marking : JJ
BAV99T
Marking : JE
SOT-523
A
D
Maximum Ratings
Operating Temperature: -55 C to +150 C
Storage Temperature: -55 C to +150 C
B
C
Electrical Characteristics @ 25 C Unless Otherwise Specified
Peak Repetitive
Reverse Voltage
Continuous
Forward Current
Power Dissipation
Peak Forward Surge
Current @t=1.0us
@t=1.0ms
@t=1.0s
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Total
Capacitance
Reverse Recovery
Time
V
RRM
I
F
P
D
I
FSM
85V
75mA
150mW
4.0A
1.0A
0.5A
715mV
855mV
1000mV
1250mV
2 A
0.03 A
1.5pF
4nS
I
F
= 1mA
I
F
= 10mA;
I
F
= 50mA
I
F
= 150mA
V
R
=75Volts
V
R
=25Volts
Measured at
1.0MHz, V
R
=0V
IF = IR = 10mA,
Irr = 0.1 x IR,
RL = 100
G
E
H
J
K
DIMENSIONS
INCHES
MIN
MAX
.059
.067
.030
.033
.057
.069
.020 Nominal
.035
.043
.000
.004
.028
.031
.004
.008
.010
.014
MM
MIN
MAX
1.50
1.70
0.75
0.85
1.45
1.75
0.50Nominal
0.90
1.10
.000
.100
.70
0.80
.100
.200
.25
.35
V
F
DIM
A
B
C
D
E
G
H
J
K
NOTE
I
R
C
T
T
rr
Revision:
B
www.mccsemi.com
1 of 3
2013/01/01
BAS16T/BAW56T
BAV70T/BAV99T
MCC
Micro Commercial Components
1
TM
300
250
I
F
, FORWARD CURRENT (mA)
200
Single diode loaded
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
0.1
T
A
= 150ºC
T
A
= 75ºC
T
A
= 25ºC
T
A
= 0ºC
T
A
= -40ºC
150
100
Double diode loaded
0.01
50
0
0
50
100
150
200
0.001
0
0.5
1.0
1.5
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Forward Characteristics
10
1
V
R
= 75V
V
R
= 20V
0.1
0.01
0.001
0.0001
0
50
100
150
200
T
j
, JUNCTION TEMPERATURE (°C)
Fig. 3, Typical Reverse Characteristics
Revision:
B
www.mccsemi.com
2 of 3
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
3Kpcs/Reel
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision:
B
3 of 3
2013/01/01
