APTDF200H60G
Diode Full Bridge
Power Module
+
AC1
AC2
V
RRM
= 600V
I
C
= 200A @ Tc = 80°C
Application
Uninterruptible Power Supply (UPS)
Induction heating
Welding equipment
High speed rectifiers
Features
Benefits
Outstanding performance at high frequency
operation
Low losses
Low noise switching
Direct mounting to heatsink (isolated package)
Low junction to case thermal resistance
RoHS Compliant
Ultra fast recovery times
Soft recovery characteristics
High blocking voltage
High current
Low leakage current
Very low stray inductance
- Symmetrical design
- M5 power connectors
High level of integration
-
All ratings @ T
j
= 25°C unless otherwise specified
Absolute maximum ratings
Symbol
V
R
V
RRM
I
F(AV)
I
F(RMS)
I
FSM
Parameter
Maximum DC reverse Voltage
Maximum Peak Repetitive Reverse Voltage
Maximum Average Forward
Current
Duty cycle = 50%
T
C
= 25°C
T
C
= 80°C
T
C
= 45°C
T
C
= 45°C
Max ratings
600
270
200
270
1500
A
Unit
V
APTDF200H60G – Rev 2 October, 2012
RMS Forward Current
Duty cycle = 50%
Non-Repetitive Forward Surge Current
8.3ms
These Devices are sensitive to Electrostatic Discharge. Proper Handling Procedures Should Be Followed. See application note
APT0502 on www.microsemi.com
www.microsemi.com
1-5
APTDF200H60G
Typical Performance Curve
Maximum Effective Transient Thermal Impedance, Junction to Case vs Pulse Duration
0.3
Thermal Impedance (°C/W)
0.9
0.25
0.2
0.15
0.1
0.05
0
0.00001
0.7
0.5
0.3
0.1
0.05
0.0001
0.001
Single Pulse
0.01
0.1
1
10
Rectangular Pulse Duration (Seconds)
Forward Current vs Forward Voltage
600
t
rr
, Reverse Recovery Time (ns)
I
F
, Forward Current (A)
500
T
J
=175°C
300
250
200
150
100
50
0
Trr vs. Current Rate of Charge
400 A
200 A
T
J
=125°C
V
R
=400V
400
300
200
100
0
0.0
0.5
1.0
1.5
2.0
2.5
3.0
V
F
, Anode to Cathode Voltage (V)
Q
RR
vs. Current Rate Charge
T
J
=125°C
V
R
=400V
400 A
T
J
=125°C
T
J
=25°C
100 A
T
J
=-55°C
400
800 1200 1600 2000 2400
-di
F
/dt (A/µs)
Q
RR
, Reverse Recovery Charge (µC)
I
RRM
, Reverse Recovery Current (A)
8
120
100
80
60
40
20
0
0
I
RRM
vs. Current Rate of Charge
T
J
=125°C
V
R
=400V
400 A
200 A
100 A
6
200 A
100 A
4
2
0
0
400
800
1200 1600 2000 2400
-diF/dt (A/µs)
Capacitance vs. Reverse Voltage
2800
2400
400
800 1200 1600 2000 2400
-diF/dt (A/µs)
Max. Average Forward Current vs. Case Temp.
300
250
I
F
(AV) (A)
200
150
100
50
0
Duty Cycle = 0.5
T
J
=175°C
C, Capacitance (pF)
2000
1600
1200
800
400
0
1
10
100
1000
V
R
, Reverse Voltage (V)
25
50
75
100
125
150
175
Case Temperature (°C)
www.microsemi.com
3-5
APTDF200H60G – Rev 2 October, 2012
