URS1V220MDD1TA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> URS1V220MDD1TA

URS1V220MDD1TA: DescriptionAluminum Electrolytic Capacitors - Leaded; CategoryPassive components; File Size248KB，2 Pages; ManufacturerNichicon; Websitehttp://www.nichicon.co.jp

Download Datasheet Parametric View All

URS1V220MDD1TA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	URS1V220MDD1TA	-	-	View	Buy Now

URS1V220MDD1TA Overview

Aluminum Electrolytic Capacitors - Leaded

URS1V220MDD1TA Parametric

Parameter Name	Attribute value
Product Category	Aluminum Electrolytic Capacitors - Leaded
Manufacturer	Nichicon
Capacitance	22 uF
Voltage Rating DC	35 VDC

Preview

Download Datasheet

View All

ALUMINUM ELECTROLYTIC CAPACITORS

URS

Compact & Low-profile Sized

Compact & low profile case size.

Compliant to the RoHS directive (2011/65/EU).

URZ

High

Temperature

URS

Specifications

Item

Category Temperature Range

Rated Voltage Range

Rated Capacitance Range

Capacitance Tolerance

Performance Characteristics

–40 to +85˚C

6.3 to 400V

1 to 10000µF

± 20% at 120Hz, 20˚C

Rated voltage

(

)

6.3 to 100

After 1 minute's application of rated voltage at 20°C, leakage current

is not more than 0.03CV or 4 (µA), whichever is greater.

After 2 minutes' application of rated voltage at 20°C, leakage current

is not more than 0.01CV or 3 (µA), whichever is greater.

6.3

0.28

0.24

0.20

6.3

0.16

0.14

0.12

0.10

160 to 400

Leakage Current

After 1 minute's application of rated voltage at 20°C,

= 0.04CV+100 (µA) or less

For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.

Measurement frequency : 120Hz at 20˚C

Tangent of loss angle (tan

δ)

Rated voltage (V)

tan

(

MAX.

)

100

0.08

160

0.20

100

200

0.20

160

200

250

0.20

250

400

0.25

400

Measurement frequency : 120Hz

Stability at Low Temperature

Rated voltage (V)

Z– 25˚C / Z+20˚C

Impedance ratio

ZT / Z20 (MAX.

)

Z– 40˚C / Z+20˚C

Endurance

The specifications listed at right shall be met when

the capacitors are restored to 20°C after the rated

voltage is applied for 2000 hours at 85°C.

Capacitance change

tan

Leakage current

Within ±20% of the initial capacitance value

200% or less than the initial specified value

Less than or equal to the initial specified value

Shelf Life

Marking

After storing the capacitors under no load at 85˚C for 1000 hours and then performing voltage treatment based on JIS C 5101-4

clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.

Printed with white color letter on black sleeve.

Radial Lead Type

Sleeve (P.E.T.)

Type numbering system (Example : 10V 330µF)

9 10 11

Size code

Configuration

P ±

0.5

URS 1 A 3 3 1 MPD

Capacitance tolerance (±20%)

Rated capacitance (330µF)

Rated voltage (10V)

φD

0.5 MAX

Pressure

relief vent

(φ8up)

Series name

L+

MAX

MIN

Type

Configuration

(mm)

5 · 6.3

8 · 10

12.5 to 18

Pb-free leadwire

Pb-free PET sleeve

φD

φd

2.0

0.5

6.3

2.5

0.5

3.5

0.6

5.0

0.6

12.5

5.0

0.6

7.5

0.8

7.5

0.8

10.0

1.0

(φD 20) 1.5

(φD 20) 2.0

•

Please refer to page 20 about the end seal configuration.

Please refer to page 20, 21, 22 about the formed or taped product spec.

Please refer to page 4 for the minimum order quantity.

Dimension table in next page.
