ALUMINUM ELECTROLYTIC CAPACITORS
UWS
Chip Type, High CV
High Temperature (260°C) Reflow
Corresponding with 260
°C peak reflow soldering
Recomended reflow condition : 260°C peak 5 sec. 230°C over 60 sec. 2 times
(
φ
8
×
6.2,
φ
10
×
10 : 1 time)
Chip type higher capacitance in large case size.
Applicable to automatic mounting machine fed with carrier tape.
Compliant to the RoHS directive (2011/65/EU).
UWS
High
Temperature
Products which are scheduled to be discontinued.
Not recommended for new designs
Reflow
UUR
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
Performance Characteristics
–40 to +85°C
6.3 to 50V
22 to 1500µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage, leakage current is not more than 0.03CV (µA) .
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
tan
δ
(MAX.)
6.3
0.28
10
0.24
6.3
5
10
16
0.20
10
4
8
25
0.16
16
3
6
35
0.14
25
2
4
35
2
3
50
0.12
Measurement frequency: 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio Z–25°C / Z+20°C
ZT / Z20 (MAX.) Z–40°C / Z+20°C
50
2
3
Endurance
The specifications listed at right shall be met when
the capacitors are restored to 20°C after the rated
voltage is applied for 2000 hours at 85°C.
Capacitance change
tan
δ
Leakage current
Within ±20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
The capacitors are kept on a hot plate for 30 seconds,
which is maintained at 250°C. The capacitors shall meet
the characteristic requirements listed at right when they
are removed from the plate and restored to 20°C.
Black print on the case top.
Capacitance change
tan
δ
Leakage current
Within ±10% of the initial capacitance value
Less than or equal to the initial specified value
Less than or equal to the initial specified value
Resistance to soldering
heat
Marking
Chip Type
(φ6.3,
φ8
×
6.2)
Voltage (A:10V)
0.3MAX.
C±0.2
0.5MAX.
Plastic platform
Series
Positive
Type numbering system (Example : 10V 100
µ
F)
1
2
3
4
5
6
7
8
9
10 11 12 13 14
UWS 1 A 1 0 1 M C L 1G S
Package code
Configuration
A±0.2 E A±0.2
Capacitance tolerance (±20%)
Rated capacitance (100μF)
Rated voltage (10V)
Series name
Type
A2
100A
WS
φD±0.5
1
Trade mark
Lot No.
Capacitance
L ±0.3
B±0.2
H
1 Size
φ8
× 6.2 only
Negative
(mm)
(φ8
×
10,
φ10
×
10)
Positive
Voltage (V:35V)
Series
C±0.2
0.5MAX.
Plastic platform
0.3MAX.
φ
D×L
6.3 × 5.8
2.4
6.6
6.6
2.2
5.8
0.5 to 0.8
6.3 × 7.7
2.4
6.6
6.6
2.2
7.7
0.5 to 0.8
8 × 6.2
3.3
8.3
8.3
2.3
6.2
0.5 to 0.8
8 × 10
2.9
8.3
8.3
3.1
10
0.8 to 1.1
10 × 10
3.2
10.3
10.3
4.5
10
0.8 to 1.1
Trade mark
Lot No.
Capacitance
L±0.5
H
Voltage
V
Code
6.3
j
10
A
16
C
25
E
35
V
50
H
A±0.2 E A±0.2
A2
100V
WS
φD±0.5
A
B
C
E
L
H
B±0.2
Negative
Dimension table in next page.
150
CAT.8100E
ALUMINUM ELECTROLYTIC CAPACITORS
UWS
Dimensions
V
Cap. (µF)
Code
6.3
0J
10
1A
16
1C
25
1E
6.3
×
5.8
6.3
×
5.8
065
145
192
250
305
393
8
×
6.2
8
×
10
8
×
10
10
×
10
10
×
10
35
1V
6.3
×
5.8
055
105
175
214
265
324
8
×
6.2
8
×
10
10
×
10
10
×
10
10
×
10
50
1H
045
095
140
195
238
289
22
33
47
100
150
220
330
470
680
1000
1500
220
330
470
101
151
221
331
471
681
102
152
8
×
6.2
8
×
6.2
8
×
10
8
×
10
10
×
10
10
×
10
160
190
265
318
400
489
6.3
×
5.8
6.3
×
5.8
8
×
6.2
8
×
10
8
×
10
10
×
10
10
×
10
070
085
175
240
290
374
454
8
×
6.2
6.3
×
7.7
8
×
10
8
×
10
10
×
10
10
×
10
125
151
215
270
330
396
8
×
6.2
8
×
10
10
×
10
10
×
10
10
×
10
Case size
φ
D
×
L (mm)
Rated
ripple
Rated ripple current (mArms) at 85°C 120Hz
Frequency coefficient of rated ripple current
Cap.(µF)
Frequency
00
Less than 47V
100 to 1500
50 Hz
0.80
0.85
120 Hz
1.00
1.00
300 Hz
1.15
1.08
1 kHz
1.40
1.20
10 kHz or more
1.67
1.30
Taping specifications are given in page 23.
Recommended land size, soldering by reflow are given
in page 18, 19.
Please refer to page 3 for the minimum order quantity.
151
CAT.8100E
