Features
■
Shielded construction
■
Inductance range: 1.0 to 1000
μH
■
Heating current up to 11 A
■
Dimensions: 12 x 12 x 10 mm
■
AEC-Q200 qualified
■
RoHS compliant* and halogen free**
AP *Ro
PR HS
OV C
ED OM
(S P L
el IAN
ec T
tM
od
el
s)
AE
C
0
10
Bourns
Part Number
SRR1210A-1R0Y
SRR1210A-1R8Y
SRR1210A-2R2Y
SRR1210A-3R3Y
SRR1210A-4R7Y
SRR1210A-5R6Y
SRR1210A-6R8Y
SRR1210A-8R2Y
SRR1210A-100M
SRR1210A-120M
SRR1210A-150M
SRR1210A-180M
SRR1210A-220M
SRR1210A-270M
SRR1210A-330M
SRR1210A-390M
SRR1210A-470M
SRR1210A-560M
SRR1210A-680M
SRR1210A-820M
SRR1210A-101M
SRR1210A-121M
SRR1210A-151M
SRR1210A-181M
SRR1210A-221M
SRR1210A-271M
SRR1210A-331M
SRR1210A-391M
SRR1210A-471M
SRR1210A-561M
SRR1210A-681M
SRR1210A-821M
SRR1210A-102M
Inductance
@ 1 kHz /
0.25 V
L
Tol.
(µH)
(%)
1.0
± 30
1.8
± 30
2.2
± 30
3.3
± 30
4.7
± 30
5.6
± 30
6.8
± 30
8.2
± 30
10
± 20
12
± 20
15
± 20
18
± 20
22
± 20
27
± 20
33
± 20
39
± 20
47
± 20
56
± 20
68
± 20
82
± 20
100
± 20
120
± 20
150
± 20
180
± 20
220
± 20
270
± 20
330
± 20
390
± 20
470
± 20
560
± 20
680
± 20
820
± 20
1000 ± 20
Q
Ref.
10
10
10
15
8
12
12
11
16
14
16
13
16
16
16
16
16
8
12
15
16
13
12
14
15
16
14
16
12
12
11
6
22
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
SRR1210A Series - Shielded Power Inductors
Operating Temperature
................................. -40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................. -40 °C to +125 °C
Resistance to Solder Heat
................................+245°C for 10 sec.
Temperature Rise
.........................40 °C typ. at rated Irms
Inductance drop .....................20 % at Isat
Q Test
Freq.
(MHz)
SRF
(MHz)
Typ.
85
56
54
44
35
28
20
16
12
18
10.5
8
8
6.5
6.5
4.5
4.5
4
3.8
3.5
3
2.6
2.2
1.8
1.8
1.8
1.8
1.3
0.85
0.85
0.85
0.85
0.85
DCR
(Ω)
Max.
0.006
0.075
0.09
0.01
0.012
0.0135
0.015
0.017
0.018
0.022
0.032
0.035
0.038
0.04
0.052
0.066
0.072
0.09
0.102
0.112
0.135
0.17
0.19
0.25
0.315
0.41
0.45
0.6
0.82
0.9
1.2
1.32
1.65
I rms
(A)
11.0
10.2
9.5
9.0
8.5
8.0
7.85
7.25
6.5
6.3
5.8
5.5
5.2
5.0
4.4
4.2
3.8
3.4
3.0
2.8
2.5
2.3
2.2
1.9
1.7
1.5
1.4
1.3
1.2
1.1
1.0
0.85
0.75
I sat
(A)
16.5
13.2
12.2
10.5
9.6
8.5
8.3
7.55
6.5
6.1
5.3
5.1
4.5
4.2
3.7
3.5
3.1
2.9
2.7
2.5
2.2
1.9
1.8
1.6
1.5
1.3
1.2
1.1
1.0
0.95
0.85
0.75
0.7
***K-
Factor
86
67
55
46
40
35
32
29
26
24
21
19
17
15
14
13
12
11
10
9
8
7
7
6
5
5
4
4
4
3
3
3
3
Materials
Core ............................................... Ferrite
Wire ..............................Enameled copper
Terminal Finish .................................... Sn
Packaging ...................... 250 pcs. per reel
(.472 ± .020)
Product Dimensions
12.0 ± 0.5
(.472 ± .020)
12.0 ± 0.5
1R0
INDUCTANCE
CODE
INDUCTANCE
CODE
12.0 ± 0.5
(.472 ± .020)
12.0 ± 0.5
(.472 ± .020)
1R0
10.0
MAX.
(.394)
10.0
MAX.
(.394)
4.9
REF.
(.193)
4.9
REF.
(.193)
7.9
REF.
(.311)
7.9
REF.
(.311)
Δ
I (peak-to-peak ripple current,
A), determine core loss from
Core Loss vs. Flux Density
plot.
How to Order
Electrical Schematic
Recommended Layout
REF.
REF.
5.3
(.209)
REF.
2.8
(.110)
REF.
2.8
(.110)
7.3
REF.
(.287)
SRR1210A - 100M
Model
Value Code (see table)
5.3
(.209)
WARNING Cancer and Reproductive Harm -
