TC9314F-043
TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic
TC9314F-043
Single Chip Digital Tuning System for CD Radio Cassette
TC9314F-043 is a CMOS LSI designed for a PLL frequency synthesizer radio system corresponded to the
requirement of the whole world.
Since TC9314F-043 can be used for TC9284BF the CD processor and receive remote control signal, a low cost
compact CD radio system can be constructed.
Features
·
Receiving band
Jumper Setting
FM Step
A0
MW Step
0
USA
0
0
1
0
1
0
1
General
0
1
0
1
―
0
FM
1
East Europe
1
0
0
1
―
―
(Note 2)
Japan
1
1
―
―
(Note 3)
MW/AM
LW
FM
MW/AM
TV
Area
A1
Band
Frequency Rang
(Hz)
87.5~107.9 M
87.5~108.0 M
530~1710 k
531~1602 k
87.50~108.00 M
87.5~108.0 M
522~1602 k
530~1602 k
146~281 k
65.00~74.0 M
87.50~108.00 M
65.00~74.0 M
87.50~108.00 M
531~1602 k
530~1610 k
146~281 k
76.0~90.0 M
522~1629 M
1~12 ch
Step
(Hz)
200 k
100 k
10 k
9k
50 k
100 k
9k
10 k
1k
50 k
50 k
100 k
9k
10 k
1k
100 k
9k
1 ch
FREF
(Hz)
25 k
5k
3k
25 k
3k
5k
1k
IF
FM
AM
(Note 1)
FM
+10.7 M
+450 k
+10.7 M
MW/AM
LW
+450 k
25 k
+10.7 M
3k
5k
1k
25 k
3k
25 k
−10.7
M
+450
−10.7
M
+450 k
Note 1: AM mark is indicated, even if band is MW with SW band in USA area.
Note 2: In case that
there is not TV band, FM band extends (76.0-90.0 MHz + TV 1~3 ch).
Note 3: If TV band is selected, prescaler (TD7104P) is need.
1
2002-02-28
TC9314F-043
There are SW bands with bands as shown above by setting of SW
0
, SW
1
Jumper.
Jumper Setting
FM Step
SW0
MW Step
0
1
0
1
―
―
―
―
―
SW
A
SW
B
SW
1
SW
2
3.8~12.5 M
5.95~15.6 M
2.3~7.3 M
9.5~26.1 M
5k
5k
+450 k
Frequency Rang
(Hz)
Step
(Hz)
no SW
FREF
(Hz)
SW1
0
0
1
1
Band
IF
Note
Note 4: Only SW mark is indicated for SWA or SWB.
Note 5: If jumper setting is SW
1
, SW
2
when there is LW/TV band, SW
1
, SW
2
bands are no set. (Maximum 4 band)
·
Tuning functions and preset memory
·
manual up/down tuning
·
seek up/down tuning
·
Preset memory
·
Fixed
FM/AM
FM/MW/LW or TV
FM/MW/SW-A or B
FM/MW/LW or TV/SW-A or B
FM/MW/SW
1
/SW
2
·
Random
·
Clock functions
·
12H/24H clock
·
TIMER on/off
·
SLEEP
·
CD functions
·
random play
·
intro play
·
repeat play or track repeat play
·
memory play (max 20 preset)
·
CD FF/REW
·
synchro rec mode
·
tray open/close control
·
indication of CD remain time
·
music calendar display
·
Remote control functions
·
volume up / down control
·
direct selecting of preset memory and track number
·
Other functions
·
preset equalizer control
·
function change (CD/TUNER/TAPE/AUX)
·
indication of STEREO mark
·
power on/off key
·
mute on/off control
total
20/20
20/10/10
20/10/10
20/10/5/5
20/10/5/5
30
stations
stations
stations
stations
stations
stations
2
2002-02-28
TC9314F-043
