Resistors
Water Insoluble Nitride Thin Film
Precision Chip Resistors
WIN Series
Make Possible
TaN thin film technology
Inherent moisture protection superior to that of passivated
nichrome chip resistors
High stability in humid and polluted environments
Typical 85°C, 85%RH biased humidity 2000 hour stability <0.1%
Typical moisture resistance stability ±100ppm
Precision ±0.05% tolerance and ±15ppm/°C
Anti-sulfur terminations
All Pb-free parts comply with EU Directive 2011/65/EU (RoHS2)
Electrical Data
T0603
Power rating @ 70°C
Resistance range
Limiting element voltage (maximum voltage)
Resistance tolerance
TCR
Standard values
Ambient temperature range
°C
watts
ohms
Vdc or
rms
%
ppm/°C
0.1
5R to 100K
75
T0805
0.25
5R to 267K
100
±0.05 ±0.1 ±0.5 ±1
±15 ±25 ±50
E24, E96, E192
-65 to +150
T1206
0.33
5R to 1M0
200
Physical Data
Dimensions in mm & (inch) and weight in mg
L
T0603
T0805
T1206
1.58 ± 0.15
(0.062 ± 0.006)
2.02 ± 0.15
(0.080 ± 0.006)
3.15 ± 0.15
(0.124 ± 0.006)
W
0.80 ± 0.10
(0.031 ± 0.004)
1.28 ± 0.15
(0.050 ± 0.006)
1.57 ± 0.15
(0.062 ± 0.006)
T
C
A
Wt. nom
2.0
4.3
9.6
C
T
L
A
W
0.45 ± 0.10
0.27 ± 0.20
0.34 ± 0.20
(0.018 ± 0.004) (0.011 ± 0.008) (0.013 ± 0.008)
0.45 ± 0.10
0.31 ± 0.20
0.40 ± 0.20
(0.018 ± 0.004) (0.012 ± 0.008) (0.016 ± 0.008)
0.50 ± 0.15
0.45 ± 0.25
0.52 ± 0.25
(0.020 ± 0.006) (0.018 ± 0.010) (0.020 ± 0.010)
Construction
Conductors, thin film resistive element and epoxy outer protection are applied to an alumina substrate. The chips are supplied with
wrap-around terminations suitable for soldering. The terminations have an electroplated nickel barrier and either 100% matt tin or 60/40 SnPb finish.
Marking & Solvent Resistance
WIN resistors have no marking on the component body. The body protection is resistant to all normal cleaning solvents suitable for printed circuits
General Note
TT Electronics reserves the right to make changes in product specification without notice or liability.
All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.
